OUTDOOR
www.elmarkholding.eu
ROAD LIGHTS
SOLAR LED STREET LIGHTS WITH SENSOR
98SOL100
98SOL101
98SOL102
IP65
Solar
SOLAR LED STREET LIGHTS WITH SENSOR
Watt
(W) Whole fixture Colour temp. Solar panel
lumens (lm) (K)
(Wp) Battery
(V/mAh) Sensor
range
(m) Length
(mm) Height
(mm) Width
(mm) Packing/Box Energy class
(pcs)
98SOL100 4 400 6000 2.3 3.7V/2400mAh 2-6 137 224.4 41.5 1/1
98SOL101 8 850 6000 7 3.7V/6000mAh 3-8 193.7 351.4 50.8 1/1
98SOL102 15 1600 6000 9.5 7.4V/5400mAh 3-8 232 413 58 1/1
Material: ABS + PC, anti UV and glossy, V0 fireproof | Colour body: Black | Detection angle: 120° | Beam angle: 140°x 70° | Installation height 98SOL001: 2-4meters, other models: 3-5m | Posibility to
mounting on Wall or Lamp-post | First 5 hours lighting: Full brightness+ Weak brightness | After 5 hours or battery capacity<30%: Full brightness+ Weak brightnes+ OFF | Solar panels: Poly-cristalline
silicone; Frosted surface- scratch resistant | LED&Lens: LM-80 LEDs 2835SMD; high transmittance PC optical lens | Accessory for wall mounted installation: included
Accessory for wall mounted installation
SMD
Ra>80
2+0
standard
+extended
2
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
813
Catalogue number
