OUTDOOR
FLOODLIGHTS
www.elmarkholding.eu
ATLAS Sim
ATLAS 45
98ATSIM105
98ATSIM106
98ATLASSIM/1
98ATLASSIM/2
98AT45102
98AT45104
98ATLAS45/BL1
98ATLAS45/BL2
ATLAS Ring
98ATR107
98ATR108
98ATLASRING/1
98ATLASRING/2
IP65
ATLAS
808
Catalogue number Watt
(W) Lampholder Colour Length1
(mm) Length2
(mm) Width
(mm) Width2
(mm) Height
(mm) Current
(A) Control gear Packing/Box Energy
(pcs)
class
98AT45102 70 Rx7s black 435 350 232 - 85 1.00 magnetic 1/4
98AT45104 150 Rx7s black 435 350 232 - 85 1,80 magnetic 1/4
98ATLAS45/BL1 70 Rx7s black 435 350 232 - 85 - empty fixture 1/4
98ATLAS45/BL2 150 Rx7s black 435 350 232 - 85 - empty fixture 1/4
98AT45101 70 Rx7s white 435 350 232 - 85 0,95 magnetic 98ATLAS45/W1 70 Rx7s white 435 350 232 - 85 - empty fixture 1/4
98ATSIM105 70 Rx7s black 232 210 280 220 170 1.00 magnetic 1/6
98ATSIM106 150 Rx7s black 232 210 280 220 170 1,80 magnetic 1/6
98ATLASSIM/1 70 Rx7s black 232 210 280 220 170 - empty fixture 1/6
98ATLASSIM/2 150 Rx7s black 232 210 280 220 170 - empty fixture 1/6
98ATR107 70 Rx7s black 325 280 230 210 93 0,95 magnetic 1/6
98ATR108 150 Rx7s black 325 280 230 210 93 1,80 magnetic 1/6
98ATLASRING/1 70 Rx7s black 325 280 230 210 93 - empty fixture 1/6
98ATLASRING/2 150 Rx7s black 325 280 230 210 93 - empty fixture 1/6
ATLAS 45 / 70W
ATLAS 45 / 150W
ATLAS sim / 70W
Body: aluminium | Diffuser: tempered glass | Control gear: mounted in the body
Ambient Temperature: -20°C ÷ +65°C
50/60
Hz
2+0
standard
+extended
2
YEAR TOTAL
WARRANTY
1/4
