OUTDOOR
FACADE AND GROUND
www.elmarkholding.eu
SOLAR LED WALL LIGHTS
WITH SENSOR
98SOL200
772
SOLAR LED WALL LIGHTS
WITH SENSOR
98SOL201
IP54
Solar
SOLAR LED WALL LIGHTS WITH SENSOR
Catalogue number LED QTY Power
(W) Whole fixtures Solar panel
lumens (lm) (Wp) Sensor Colour of Length
range body
(mm)
(m) Height
(mm) Width
(mm) Packing/ Energy
Box
class
(pcs)
98SOL200 14 (FRONT 14+BACK 2PCS) 1.5 200 0.7- POLY CRISTALLINE 6 white 144.5 96 79 1
98SOL201 17 (FRONT 16+BACK 1PCS) 2 240 0.7- POLY CRISTALLINE 6 white 200 105 90 1
Material: ABS + PC, anti UV and glossy | LED&Lens: LM-80 LEDs 2835SMD; high transmittance PC optical lens | Detection angle: 120° | Installation height: ≤ 4meters | Battery: 3.7V/ 1200mAh
98SOL200 Auto on at night; Full brightnessby motion activated. Weak brightness when no motion | Time delay: 10 sek | Modes: A- Full brightness+Weak brightness (front and back lights ON); B- Full
brightness+Weak brightness (front light OFF, back lights ON) | Auto on at night; Full brightnes
98SOL201 Auto on at night; Full brightnessby motion activated. Weak brightness when no motion | Time delay: 10 sek | Battery >30%: Full brightness+Weak brightness (front and back lights ON);
Battery<30%: Full brightness+Weak brightness (front light OFF, back lights ON) | Auto on at night; Full brightnes
98SOL200
SMD
3
54
98SOL201
2+0
standard
+extended
2
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
