OUTDOOR
GARDEN
www.elmarkholding.eu
OL9613-W LED
9613LEDW
GRF9620
9620LEDW
754
IP54
OL9613-W LED
Catalogue number Watt
(W) Whole fixture lumens Colour temp.
(lm)
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
9613LEDW 6 360 4000-4300 dark grey 210 60 32 1/16
9620LEDW 6* 480 4000-4300 dark grey 220 90 133 1/12
Energy class
Body 9613LEDW: polycarbonate (PC) | Body 9620LEDW: aluminium | Diffuser 9613LEDW: polycarbonate (PC) | LED driver 9613LEDW: mounted in the body | Light source 9613LEDW: 30 pcs SMD
LED Epistar | Light source 9620LEDW: Osram LED recessed fixture | LED driver 9620LEDW: mounted in the body
Operating temperature: -20°C÷+65°C
* Until Supply Last
50/60
Hz
Ra>80
>15000
3
54
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
