INDOOR
www.elmarkholding.eu
LUMINAIRES
IP20
RAINBOW LED SMD
Colou LED lamp lumens
(lm) Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
9RT5300/WH 5 White 400 320 22 35 1/25
9RT5300/WW 5 Warm white 400 320 22 35 1/25
9RT5300/R 5 Red - 320 22 35 1/25
9RT5300/G 5 Green - 320 22 35 1/25
9RT5300/B 5 Blue - 320 22 35 1/25
9RT5600/WH 9 White 720 555 22 35 1/25
9RT5600/WW 9 Warm white 720 555 22 35 1/25
9RT5600/R 9 Red - 555 22 35 1/25
9RT5600/G 9 Green - 555 22 35 1/25
9RT5600/B 9 Blue - 555 22 35 1/25
9RT5900/WH 14 White 1120 860 22 35 1/25
9RT5900/WW 14 Warm white 1120 860 22 35 1/25
9RT5900/R 14 Red - 860 22 35 1/25
9RT5900/G 14 Green - 860 22 35 1/25
9RT5900/B 14 Blue - 860 22 35 1/25
9RT51200/WH 18 White 1440 1165 22 35 1/25
9RT51200/WW 18 Warm white 1440 1165 22 35 1/25
9RT51200/R 18 Red - 1165 22 35 1/25
9RT51200/G 18 Green - 1165 22 35 1/25
Energy class
9RT505
Body: PVC | Diffuser: Glass | Light source: SMD 2835
50/60
Hz
SMD
2835
Ra>80
>20000
3
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
Light is one of the most important space-shaping elements. Therefore it is worth to consider the quality of the selected lighting fittings.
The SMD LED series of modern fittings is an innovative solution of lighting that is functional and decorative at the same time. The fittings emit high quality light and their compact form, matching
contemporary furniture, enables a multitude of arrangements. The fittings can be connected in order to achieve the lighting line of the desired length, and the energy-efficient LED light makes it
possible to achieve a spectacular effect in any interior.
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Watt
(W)
693
Catalogue number
