INDOOR
www.elmarkholding.eu
TRACK LIGHTING
POWER SUPPLY
I - TYPE
L - TYPE
SOFT L - TYPE
T - TYPE
FOUR LINES TRACK RAILS
X - TYPE
IP20
Catalogue number
WHITE Catalogue number
BLACK Type Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
94101 94301 four lines track rails* 1000 33.5 42 1/10
94102 94302 four lines track rails* 2000 33.5 42 1/10
94110 94310 four line I-type connector 160 30 42 1/50
94120 94320 four line L-type connector 100 30 100 1/70
94120M 94320M four line soft L-type connector 100 30 100 1/70
94130 94330 four line T-type connector 160 30 100 1/50
94140 94340 four line X-type connector 160 30 160 1/25
94150 94350 four line power supply 160 30 42 1/100
94160 94360 end cap
Material: track rails- aluminium | Accessories: ABS antiflaming + cooper sheet
*four lines track rails come without power supply
50/60
Hz
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
1/100
681
FOUR LINES TRACK RAILS AND ADAPTERS
