INDOOR
LED PANELS
www.elmarkholding.eu
LED PANEL
WITH EMERGENCY KIT
92PANEL012WE
92PANEL018WE
92PANEL014WE
92PANEL014WCWE
LED PANEL
WITH EMERGENCY KIT
92PANEL013WE
92PANEL015WE
IP40
628
LED PANEL WITH EMERGENCY KIT
Catalogue number Dimmable Type Watt
(W) Whole fixture
lumens (lm) Colour temp.
(K) Colour body Diameter/Length Height
(mm)
(mm) Width
(mm) Packing/Box Energy class
(pcs)
92PANEL012WE - square 24 2400 4000-4300 white 295 295 11 1/1
92PANEL013WE - tetragon 36 3600 4000-4300 white 595 295 11 1/1
92PANEL018WE Yes square 45 4500 4000-4300 white 595 595 9 1/1
92PANEL015WE - tetragon 45 4500 4000-4300 white 1195 295 11 1/1
92PANEL014WE - square 45 4500 4000-4300 white 595 595 11 1/1
92PANEL014WCWE - square 45 4500 6000-6400 white 595 595 11 1/1
5 YEAR TOTAL
WARRANTY
We offer the fixtures as per personal
request with a fixed block and battery
with a possibility for work in an
emergency regime up to three hours.
Body: aluminium | Light source: Epistar SMD | Starting time: <0.5s | Power factor: λ>0.8 | Easy installation due to handy clips | Recessed mounted luminaire.
50/60
Hz
SMD
120
Ra>80
>20000
3
40
3+2
standard
+extended
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
