INDOOR
www.elmarkholding.eu
LED PANELS
LED PANEL STELLAR 40W
99XPANEL014W
99XPANEL014CW
LED PANEL STELLAR 36W
99XPANEL016
LED PANEL STELLAR 40W
99XPANEL015W
IP40
LED PANELS STELLAR
Watt
(W) Whole fixture lumens
(lm) Colour temp.
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
99XPANEL016* 36 3240 4000 white 595 595 19 1/2
99XPANEL014W 40 3600 4000 white 595 595 30 1/5
99XPANEL014CW 40 3600 6400 white 595 595 30 5/5
99XPANEL015W 40 3600 4000 white 295 1195 9 1/5
99XPANEL015 40** 3600 4000 aluminium 295 1195 9 1/5
Panel frame for
595/595 mm
ceiling mounting
white
Catalogue number:
92FRAME014W
*Suitable for surface and ceiling mounting. | Body: Iron+PS | 1YEAR WARRANTY
Suitable for mountig in suspended celling Armstrong type (in grid cellings)
Body: aluminium | Light source: SMD 4014 | Starting time: < 0.5s | Power factor: 0.9 | Recessed mounted luminaire | **Until Supply Last
50/60
Hz
SMD
120
Ra>80
>10000
40
2+0
standard
+extended
2
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
YEAR TOTAL
WARRANTY
Energy class
609
Catalogue number
