CHASSIS
57
5 & 7 LEAF TANDEM SPRING
ASSEMBLIES ON FLAT BAR
SPRINGS
Size
(mm)
Rating
(kg)
REAR HANGER SUIT SLIPPER
SPRING
UNBUSHED 7/8 EYE RB
4 leaf
45 x 6 x 762
296
036315
6 leaf
45 x 6 x 762
445
036314
4 leaf
45 x 6 x 610
365
036316
6 leaf
45 x 6 x 840
395
036317
SLIPPER AUSTRALIAN MADE
Rating shown are per side.
Suit 45mm slipper spring
036368
SHACKLE BOLTS/NUTS
Non Greaseable Spring Assemblies
5 leaf
TA1500
750
036348
7 leaf
TA2000
1000
036349
2 leaf
45 x 6.5 x 720
160
036318
7 leaf
TA2000-16
1000
036350
Bolts & Nuts Greasable
3 leaf
45 x 6.5 x 720
300
036319
6 leaf
TA600
750
036351
3 1/2” x 9/16”
036369
4 leaf
45 x 6.5 x 720
450
036320
3 1/2” x 5/8”
036370
5 leaf
45 x 6.5 x 720
500
036321
6 leaf
45 x 6.5 x 720
600
036322
Front spring only suit TA1500
036352
3 1/2”x 9/16”
036371
8 leaf
45 x 6.5 x 720
800
036323
Rear spring only suit TA1500
036353
3 1/4”x 5/8”
036372
5 leaf
45 x 6.5 x 585
650
036324
Front spring only suit TA2000
036354
Rear spring only suit TA2000
036355
SLIPPER DACROMET IMPORTED
3 leaf
4 leaf
45x 6 x 720
45 x 6 x 720
300
400
036333
Spring Only
Bolts & Nuts Non-Greasable
TANDEM AXLE SPRING FITTINGS
Nuts
9/16” Nyloc nut UNF
036373
5/8” Nyloc nut UNF
036374
036334
1/2” Whitworth nut Nyloc
006530
1/2” Whitworth nut zinc plated
006531
5 leaf
45 x 6 x 720
500
036335
6 leaf
45 x 6 x 720
600
036336
7 leaf
45 x 6 x 720
675
036337
PARABOLIC SLIPPER SPRINGS
GALVANISED 45MM WIDE
Bolt
3 1/2” x 1/2” Whitworth hex bolt
Fabricated Rocker Arm
with Bushes
036375
SHACKLE PLATES
036360
1/2” hole
Black - holes 65mm centre to centre 036377
Tandem Cast Rocker Arm
TA2000 A676
036362
1 leaf spring tapered from centre to each end.
One size fitting for all capacities.
1 leaf
45 x 13 x 860
300
45 x 15 x 860
500
9/16” hole
Black - holes 65mm centre to centre 006526
036338
1 leaf
Galvanised - holes 75mm centre to centre
036378
036339
Galvanised - holes 75mm centre to centre
036379
SPLIT PIN
Tandem Cast Rocker Arm
TA2000-16
OFF ROAD AUSTRALIAN MADE
036363
FRONT SPRING U HANGER
32mm x 3.2mm steel
036422
FISH PLATES
Includes U bolt kit
45mm wide
7 leaf
60 x 6.5 x 850
500
