EAVS Catalogues Audipack Catalogue_2018 | Page 96

94
Flat panel solutions
Pop up lift systems
Telescopic pop up lift systems
Power supply: 230 VAC 50-60 Hz / 24 VDC
Ref.
P3674 Single column lift
Dimensions in mm
W 400 x D 213 x H 585-1260
Nett stroke
675
Presentation height( centre screen)
1056
Mounting interface
VESA 75, 100, 200 & L & S 3
Connectivity
Contact relay
Max.“
42
Optional wall switch, IR / RF remote or bluetooth receiver
45 Max.
Ref.
P5321 Single column lift
Dimensions in mm
W 860 x D 290 x H 880-1845
Nett stroke
965
Presentation height( centre screen)
1465
Max. mounting range in mm.
W 810 x H 446
Min. mounting range in mm.
W 130
Connectivity
Contact relay
Optional wall switch, IR / RF remote
Max.“
55
Max.
50
Ref. FPL-1010
Dimensions in mm
W 424 x D 249 x H min. 925
Nett stroke
999
Presentation height( centre screen)
1533-1633
Max. mounting range in mm.
W 670 x H 446
Min. mounting range in mm.
W 174 x H 100
Connectivity
Contact relay
Optional wall switch, IR / RF remote
Max.“
65
Max.
100
Ref. FPL-100E
Dimensions in mm
W 716 x D 171 x H 1320
Nett stroke
1300
Presentation height( centre screen)
2000
Mounting interface
VESA 400 x 200, 400 x 400,
600 x 200, 600 x 400
Connectivity
Contact relay
Optional wall switch & IR / RF remote
Max.“
90
Max.
120
Ref.
FTL-1510B
Dimensions in mm W 495x D 130 x H 600
Max screen size
W410 x D70 x H360
Mounting interface
VESA 100 & 200
Connectivity
RS485 / 232, RF remote
Max load.
8.5 KG
Anti-pinch, safety system
* Screen not included
Ref.
FTL-2210B
Dimensions in mm W 615 x D 130 x H 660
Max screen size
W530 x D70 x H380
Mounting interface
VESA 100
Connectivity
RS485 / 232, RF remote
Max load.
8.5 KG
Anti-pinch, safety system
* Screen not included
Ref.
FTL-2410B
Dimensions in mm W 675 x D 130 x H 660
Max screen size
W590 x D70 x H380
Mounting interface
VESA 100
Connectivity
RS485 / 232, RF remote
Max load.
8.5 KG
Anti-pinch, safety system
* Screen not included www. audipack. com
