Flat panel solutions 89
Wall mounted lift systems
Wall mounted lift system
Ref.
Height adjustable in mm 650 Wall offset in mm 100 Mounting interface Connectivity
Power Optional
DWS-T100E
VESA 400 x 200, 400 x 400, and L & S5 Hand control included, contact relay Optional wall switch, RF remote or bluetooth receiver 230 VAC 50-60Hz / 24 VDC soundbar, use LSS-DWS-T for mounting.
Max.
100
Electric height adjustable wall lift systems
Ref.
DWS-120E
Dimensions in mm
W1010 x H2300 x D125
Presentation height in mm
700-1580( centre screen)
Mounting interface
VESA 400 x 200, 400 x 400,
600 x 200, 600 x 400 and L & S5
Connectivity
RF remote included
Power
230 VAC 50-60Hz
Max.
100
Max.
120
Ref. DWS-160E
Dimensions in mm
W1010 x H2300 x D125
Presentation height in mm
700-1580( centre screen)
Mounting interface
VESA 400 x 200, 400 x 400,
600 x 200, 600 x 400 and L & S5
Connectivity
Contact relay
Optional wall switch & IR / RF remote
Power
230 VAC 50-60Hz
Max.
100
Max.
160
Floor lift system for flat panels
Ref.
FSL-160E
FSL-160E-XL
Dimensions in mm
W 860 x H 1719 x D 147
W 860x H 1953 x D 147
Presentation height in mm Mounting interface
899- 1399( centre screen) Up to VESA 800x600
913- 1653( centre screen) Up to VESA 800x600
Max.
150
Power
230 VAC 50-60Hz
230 VAC 50-60Hz
Optional:
FSL-160-FMP: FSL-160-WM: FSS-160-LTS:
Floor mounting plate for FSL-160E & FSL-160E-XL Wall mounting set for FSL-160E & FSL-160E-XL Laptop shelf for FSL-160E & FSL-160E-XL. Also suitable for FSW-T160B, FSW-T160-XL, FSW-T160BT, see page 48 for more info.
