P rojector solutions
P ulley service lift systems
Bring projectors to service height
in
storage position
10 minutes...
Save time and money by using the Audipack pulley lift
systems
These lift systems are especially designed to lower projectors from
the ceiling for fast maintenance in a safe and controlled manner.
projection position
The projector receives power and data signals through special
connectors, which are disconnected when it is lowered and which
restore contact when the lift is fully retracted. You can even connect
HD signals with the standard supplied connector sets.
Pulley lifts are equipped with safety hooks to secure the projector in
the retracted position. The projector will return to this exact position
in the ceiling thanks to four centring points on the lift, ensuring the
correct position of the projected image.
All this contributes to a safer, more flexible way of presenting and
servicing.
The combination lift systems are available as standard in two
service position
models, in different sizes and lifting capacities.
An Audipack projector mount is needed to fix the projector to the
system.
Note:
For distribution HD signal use standard available
“long distance HDMI twisted pair extender” solutions!
Durable built
Low maintance
Quick installation
Low noise engine
Standard connector configuration
Top D-sub connector
1-phase 230 V 16 A with 1 early make, late break ground pin
Middle & lower connector
6 coaxial contacts 75 Ohm
1 early make, late break ground pin
17 signal pins
