P rojector solutions
C eiling lift systems
S cissor lift with integrated R ota -K it
Movable frame dimensions: W
700 x D 700 mm
Ref. P3310
Overall stroke in mm 1275
Dimensions in mm W 822 x D 811 x H 375
Number of scissors 2
Connectivity Contact relay
Optional wall switch or IR/RF remote
Max.
20
Ref. P5357
Power supply: 230 VAC 50-60 Hz
Overall stroke in mm 2300
Dimensions in mm W 822 x D 811 x H 430
Number of scissors 4
Connectivity Contact relay
Optional wall switch or IR/RF remote
Max.
20
ACCESSORIES
S ervice hatches
Internal hatch dimensions:
430 x 430 mm
Ref.
P1913
P1913 P5066
Service hatch for normal ceilings
S ilencer
P5066
Service hatch for plastered ceilings
mounting bracket
Ref.
Suitable for
Max. weight
P7010
1070 & 1090
70 Kg
P6491
1090
125 Kg
C eiling finishing mask
Ref.
Suitable for
P3136 (CFM-1060)
1060
P3733 (CFM-1070)
1070
www.audipack.com
P3732 (CFM-1090)
1090
145
