Projector solutions 121
Ceiling mounts
Quatro-Fix
Max. load
20 kg 10 kg
Mounting range in mm 440 in diameter
Angle adjustment in degrees 15 ° + 15 °
Ref.
QFIX-0100
Length in mm
100
Tube diameter in mm
54
Ref.
QFIX-0300
Length in mm
300
Tube diameter in mm
54
Ref.
QFIX-0500T
Length in mm
355-500
Tube diameter in mm
54-60
Ref.
QFIX-0700T
Length in mm
450-700
Tube diameter in mm
54-60
Ref.
QFIX-1000T
Length in mm
604-1000
Tube diameter in mm
54-60
20 Max.
20 Max.
20 Max.
20 Max.
20 Max.
Quatro-Fix XL
Mounting range in mm W336 x D 382
Max. load
20 Kg. 30 kg
Angle adjustment in degrees 15 ° + 15 °
Ref.
QFIX3-0100
Length in mm
100
Tube diameter in mm
54
Ref.
QFIX3-0300
Length in mm
300
Tube diameter in mm
54
Ref.
QFIX3-0500T
Length in mm
355-500
Tube diameter in mm
54-60
Ref.
QFIX3-0700T
Length in mm
450-700
Tube diameter in mm
54-60
Ref.
QFIX3-1000T
Length in mm
604-1000
Tube diameter in mm
54-60
Max.
30
Max.
30
Max.
30
Max.
30
Max.
30
Universal tube set
Angle adjustment in degrees 15 ° + 15 °
Ref.
UTS-0100
Length in mm
100
Tube diameter in mm
54
Ref.
UTS-0300
Length in mm
300
Tube diameter in mm
54
Ref.
UTS-0500T
Length in mm
355-500
Tube diameter in mm
54-60
Ref.
UTS-0700T
Length in mm
450-700
Tube diameter in mm
54-60
Ref.
UTS-1000T
Length in mm
604-1000
Tube diameter in mm
54-60
Max.
30
Max.
30
Max.
30
Max.
30
Max.
30 www. audipack. com
