F lat panel solutions
F old down ceiling lift systems
S urface mounted F old down lift systems
Standard VESA 100 x 200, 200 x 200, 200 x 400
and 400 x 400, no additional bracket required
Ref. FFCL-3032S
Max. “
Dimensions in mm Approx. W 1200 x D 750 x H 100
Max. flat panel in mm
Connectivity
W 980 x D 50 x H 595
Contact relay, RS-232
Optional wall switch & IR/RF remote
Ref. FFCL-4046S
32
Max.
20
RS-232
Max. “
Dimensions in mm Approx. W 1400 x D 1000 x H 100
Max. flat panel in mm
Connectivity
W 1120 x D 50 x H 675
Contact relay, RS-232
Optional wall switch & IR/RF remote
46
Max.
20
RS-232
“Registered design, patent pending”
Power supply: 100-240VAC/5A 50-60 Hz
F old down lift systems ( in - ceiling )
Standard VESA 200 x 200, 400 x 200,
600 x 200 and 800 x 400
Ref. FFCL-3032
Max. “
Dimensions in mm W 1416 x D 963 x H 165
Max. flat panel in mm W 980 x D 140 x H 595
Ref. FFCL-4042
W 1496 x D 1058 x H 165
Max. flat panel in mm W 1060 x D 140 x H 690
50
42
Max.
50
Max. “
Dimensions in mm W 1586 x D 1128 x H 165
Max. flat panel in mm W 1150 x D 140 x H 760
Ref. FFCL-5255
Power supply: 230 VAC 50-60 Hz/24 VDC
Max.
Max. “
Dimensions in mm
Ref. FFCL-4650
Connectivity:
Contact relay, wall switch, IR/RF remote or
bluetooth receiver
32
50
Max.
50
Max. “
Dimensions in mm W 1776 x D 1258 x H 210
Max. flat panel in mm W 1340 x D 175 x H 840
Ref. FFCL-6065 (with safety clamp)
Dimensions in mm W 1972 x D 1520 x H 2
Max. flat panel in mm W 1620 x D 155 x H 1045
55
Max.
50
Max. “
65
Max.
50
ACCESSORIES
W all switch
R emote control
Only suitable for fold down
ceiling lift with just falling ceiling
part.
Ref. 261318
Ref.
www.audipack.com
260214 (IR)
260215 (RF)
