Radial carriage only
Conveyor
566
567
568
569
596
597
598
599
5126
5127
5128
5129
Conveyor
Sub frame may be used with standard EK600, EK900 or EK1200
sections.
7.66m
8.86m
10.06m
11.26m
600 Code 900 Code 1200 Code
Construction
Galvanised mild steel box construction for durability.
Wheels
Two solid tyred wheels.
Height Adjustment
Twin telescopic struts with pins provide variable discharge height.
Hydraulic ram with hand pump included as standard for ease of
lifting and lowering. Ram fitted with hose burst safety valve.
Conveyor
Length
A
B
C
D
E
F
G
H
Radius
Undercarriage Weight
Approximately 500kg depending on exact model.
7.66m 2600mm 3900mm 15° 27° 6400mm 7000mm 2350mm 1800mm 4500mm
8.86m 2900mm 4450mm 15° 27° 7450mm 8100mm 3500mm 2850mm 4500mm
10.06m 2800mm 4400mm 13° 23° 8800mm 9400mm 4100mm 3500mm 5200mm
11.26m 3100mm 4850mm 13° 23° 9900mm 10550mm 5250mm 4650mm 5200mm
Longer lengths available - please ask for details
