MINIMILL Typ Z22 Nut- und Formzirkularfräsen für metrisches ISO-Gewinde
innen Vollprofil Bohrungs-Ø ab 22 mm
groove milling by circular
interpolation for metric standard threading
internal full profile bore Ø from 22 mm
X
X
H1
Fräserschaft
shank face
Beispielzeichnung
exemplary application
350
0.19 0.81 3
21.7 0.22 0.95 3
Z22.1020.02 M27 2.00 5.85 4.6 21.7 0.25 1.08 3
Z22.1630.02 M30 3.00 5.85 4.3 21.7 0.37 1.62 3
Z22.1835.02 M30 3.50 5.85 4.0 21.7 0.43 1.89 3
Z22.2140.02 M33 4.00 5.85 3.9 21.7 0.50 2.16 3
Z22.2445.02 M33 4.50 5.85 3.7 21.7 0.56 2.43 3
Weitere HM Sorten können Sie in der Sorten-
übersicht im Kapitel "Technische Hinweise" und
der Preisliste finden. More carbide grades you can find in the grades
summary in the chapter "technical instructions"
and in the price list.
Bestellbeispiel:
für Sorte AL41F:
Z22.0815.02/AL41F order-example:
grade AL41F:
Z22.0815.02/AL41F
21.7 4.7
for
4.8 5.85 5.85 1.75
Fräserschaft
1.50 M27 M24 Z22.0917.02 Z22.0815.02
dimensions in mm
Abmessungen in mm
