MINIMILL Typ Z18 Nut- und Formzirkularfräsen für metrisches ISO-Gewinde
innen Vollprofil Bohrungs-Ø ab 18 mm
groove milling by circular
interpolation for metric standard threading
internal full profile bore Ø from 18 mm
X
X
H1
Fräserschaft
shank face
Beispielzeichnung
exemplary application
0.18 0.81 3
17.7 0.20 0.95 3
Z18.1020.02 M22 2.00 5.85 4.6 17.7 0.25 1.08 3
Z18.1325.02 M24 2.50 5.85 4.4 17.7 0.31 1.35 3
Z18.1630.02 M27 3.00 5.85 4.3 17.7 0.37 1.62 3
Z18.1835.02 M27 3.50 5.85 4.0 17.7 0.43 1.89 3
Weitere HM Sorten können Sie in der Sorten-
übersicht im Kapitel "Technische Hinweise" und
der Preisliste finden. More carbide grades you can find in the grades
summary in the chapter "technical instructions"
and in the price list.
Bestellbeispiel:
für Sorte AL41F:
Z18.0815.02/AL41F order-example:
grade AL41F:
Z18.0815.02/AL41F
17.7 4.7
for
4.8 5.85 5.85 1.75
Fräserschaft
1.50 M22 M22 Z18.0917.02 Z18.0815.02
dimensions in mm
Abmessungen in mm
