MINIMILL Typ Z616 / Z616.X Nut- und Formzirkularfräsen Nutfräsen allgemein Bohrungs-Ø ab 16 mm
groove milling by circular
interpolation for groove milling general use bore Ø from 16 mm
Z616 geradverzahnt / spur-toothed
Z616.X kreuzverzahnt / cross-toothed
Schneide / tooth 2-4-6
Schneide / tooth 1-3-5
R
t max.
t max.
2.5 6
1.5 2.5 6
Z616.0200.02 16 4.5 0.2 15.7 2.0 2.5 6
Z616.X200.02 16 4.5 0.2 15.7 2.0 2.5 6
Z616.0250.02 16 4.5 0.2 15.7 2.5 2.5 6
Z616.X250.02 16 4.5 0.2 15.7 2.5 2.5 6
Weitere HM Sorten können Sie in der Sorten-
übersicht im Kapitel "Technische Hinweise" und
der Preisliste finden. More carbide grades you can find in the grades
summary in the chapter "technical instructions"
and in the price list.
Bestellbeispiel:
für Sorte AL41F:
Z616.X150.02/AL41F order-example:
grade AL41F:
Z616.X150.02/AL41F
1.5 15.7
for
15.7 0.2 0.2 4.5
Fräserschaft
4.5 16 16 Z616.X150.02 Z616.0150.02
dimensions in mm
Abmessungen in mm
