MIKROMILL Typ MB6 / MB8 Nut- und Formzirkularfräsen metrisches ISO-Feingewinde,
Teilprofil Bohrungs-Ø ab 6 mm
groove milling
by circular interpolation metric ISO-fine thread milling,
partial profile bore Ø from 6 mm
L1
X
L2
°
60
b
s
Version B / Schaft nach DIN 6535B
version B / shank acc. DIN 6535B
dimensions in mm
0.5-1.5 15 58 0.06 1.6 0.91 6 3.5 5.8 3
M9 0.5-1.5 25 68 0.06 2.0 0.91 8 5.5 7.8 3
MB8.1020.01-25 M10 1.0-2.0 25 68 0.12 2.0 1.19 8 5.0 7.8 3
Weitere HM Sorten können Sie in der Sorten-
übersicht im Kapitel "Technische Hinweise" und
der Preisliste finden. More carbide grades you can find in the grades
summary in the chapter "technical instructions"
and in the price list.
Bestellbeispiel:
für Sorte AL41F:
MB6.0815.01-15/AL41F order-example:
grade AL41F:
MB6.0815.01-15/AL41F
M7 MB8.0815.01-25 MB6.0815.01-15
Abmessungen in mm
284
Beispielzeichnung
exemplary application
P18C
X
h6
DS
