ROtaline
Abmessungen und Merkmale
Ausspindeln
ab Ø 0.4 mm
precision boring
starting at Ø 0.4 mm
characteristics
50
44
Ø Ds
44
268
Gewicht / weight
kg Ausdrehbereich / boring range
A
0.42 0.4 - 15
•
•
•
•
•
•
•
•
• • Easiest possible handling thanks to digital display
• Feed-in accuracy 0.002 mm in diameter
• 1.2 mm radial stroke adjustment
• Continuously variable
axially-adjustable cutting tools
• Automatically defined cutting edge position
• Cylindrical shaft for flexible applications
• Internal coolant supply for all accessory parts
• Manual precision balancing through balancing weights
• Protected against water and dust according to IP65
Einfachste Handhabung dank Digitalanzeige
Zustellgenauigkeit 0.002 mm im Durchmesser
1,2 mm radiale Hubverstellung
Stufenlos axial einstellbare Schneiden
Automatisch definierte Schneidenlage
zylindrischer Schaft für flexible Anwendungen
Innere Kühlschmierstoffzufuhr bei allen
Zubehörteilen
Manuelle Feinwuchtung über
Ausgleichsgewichte
Wasser- und staubgeschützt gemäß IP65
max. Tiefe Ø 8
