Typ / type NHV15 von Längsnuten nach
5° 5°
DIN 138 und DIN
6885 Klemmhalter
mit innerer Kühlmittelzufuhr ab Bohrung Ø 15.0 mm
broaching keyways according
DIN 138 and DIN 6885 toolholder
with internal cooling bore Ø from 15.0 mm
NUTSTOSSEN
d2 d2
L L
B B
L2 L2
h h d g6
d g6
d1 d1
L1 L1
NHV.15.IK25.1
NHV.15.IK25.2
NHV.15.IK25.3
d min. dg6
15.0
15.0
15.0
L1
L
L2
h
25.0 35.0 75.0 25.0 23.0
25.0 50.0 90.0 40.0 23.0
25.0 70.0 110.0 60.0 23.0
f d1
8.4
8.4
8.4 33.0
33.0
33.0
für Nutstossgeräte
for broaching device
Version / version
Ersatzteile
Schraube M4-NH15
Schlüssel Torx TX15
252
»Schwarzer 1«
»Schwarzer 2 in 1«
»EWS Slot« + »Benz LinA«
»Marchetti«
»WTO«
Bestellnummer
part number Lieferzeit
time of delivery
NHV.15.0012.1
NHV.15.0015.1
NHV.15.0016.1
NHV.15.MT16.1
NHV.15.WT16.1 max.
max.
max.
max.
max.
4
4
4
4
4
Wochen
Wochen
Wochen
Wochen
Wochen
/
/
/
/
/
spare parts
screw M4-NH15
key
Torx TX15
weeks
weeks
weeks
weeks
weeks
Klemmhalter für angetriebene Stosswerkzeuge
special toolholder for driven slotting tool
