PURE 500 +
PRODUCT DESCRIPTION
The PURE500 + is a two-component epoxy adhesive anchoring system . The system includes injection adhesive in plastic cartridges , mixing nozzles , dispensing tools and hole cleaning equipment . The PURE500 + is a high strength adhesive designed for various applications and hole drilling techniques including diamond coring . It is suitable for bonding anchor steel elements to cracked and uncracked concrete , and also approved for water filled holes . PURE500 + is also very suitable for bonding rebars to concrete as post-installed rebar application . The adhesive is approved for a medium range of ambient temperatures and is relatively slow setting .
SYSTEM COMPONENTS
PURE 500 +
GENERAL APPLICATIONS AND USES
Pure500 + Epoxy
Threaded Rod
0˚C
72 / 50 ° C 40 / 24 ° C
Reinforcing Bar
FEATURES AND BENEFITS
• Designed for use with threaded rod or reinforcing bar in uncracked and cracked concrete
• Consistent performance in uncracked and cracked concrete of variable strength
• Wide range of steel element diameter and embedment depth
• Superior bond strength for the most demanding applications
• Flexible fixture thicknesses
• Simple installation and low cleaning effort
• Versatile low odor formula with relatively long working and curing time
• Various drilling techniques including diamond coring
• Cartridge design allows multiple uses using extra mixing nozzels
STEEL GRADES
Carbon Steel 4.6 , 4.8 , 5.6 , 5.8 , 8.8 Stainless Steel A2 , A4 High Corrosion Resistance Steel HCR Rebar f y
= 400 to 600 MPa
APPROVALS
• ETA-20 / 1287
• ESR-4809
31
