DeWalt 2026 Catalogue | Page 87

CONCRETE

26MM 3-MODE SDS-PLUS ® HAMMER

D25133K

Power Input	800W
Operation Modes	Rotary Hammering,
Drilling only, Chipping only
Impact Energy( EPTA)	2.6J
Max. Drilling Capacity in Concrete	26mm
Optimum Drilling Capacity in Concrete	4-16mm
Max. Drilling Capacity	50 / 30 / 13mm
in Core Bit / Wood / Metal
No Load Speed	0-1500RPM
Beats Per Minute	0-5500BPM
Weight	2.6kg
Size( Length x Height)	335mm x 210mm
Vibration Levels	15.4m / s ²

28MM 3-MODE SDS-PLUS ® HAMMER

D25143KA

Power Input	900W
Operation Modes	Rotary Hammering,
Drilling only, Chipping only
Impact Energy( EPTA)	3J
Max. Drilling Capacity in Concrete	28mm
Optimum Drilling Capacity in Concrete	4-18mm
Max. Drilling Capacity	65 / 30 / 13mm
in Core Bit / Wood / Metal
No Load Speed	0-1450RPM
Beats Per Minute	0-5350BPM
Weight	3.1kg
Size( Length x Height)	340mm x 210mm
Vibration Levels	14.9 m / s ²

28MM 3-MODE SDS-PLUS ® HAMMER- with Quick Chuck Change

D25144K

Power Input	900W
Operation Modes	Rotary Hammering,
Drilling only, Chipping only
Impact Energy( EPTA)	3J
Max. Drilling Capacity in Concrete	28mm
Optimum Drilling Capacity in Concrete	4-18mm
Max. Drilling Capacity	65 / 30 / 13mm
in Core Bit / Wood / Metal
No Load Speed	0-1450RPM
Beats Per Minute	0-5350BPM
Weight	3.1kg
Size( Length x Height)	360mm x 210mm
Vibration Levels	14.9 m / s ²

43
