DeWalt 2026 Catalogue | Page 60

20V SDS-PLUS ® HAMMER
DCH253M2
Battery Capacity
4Ah
Operation Modes
Rotary Hammering,
Drilling, Chipping only
Impact Energy( EPTA)
2.1J
Max. Drilling Capacity in Concrete
24mm
Optimum Drilling Capacity in Concrete
10-20mm
Max. Drilling Capacity in Wood / Metal
26 / 13mm
No Load Speed
0-1200rpm
Beats Per Minute
0-4500bpm
Weight
2.5kg
( Bare without Battery Pack)
Size( Length x Height)
301mm x 202mm
Vibration Levels
6.6m / s 2
CONCRETE WORKING
60V MAX 3-MODE SDS-PLUS ® HAMMER
DCH333NT
Operation Modes
Rotary Hammering,
Drilling only, Chipping only
Impact Energy( EPTA)
3.5J
Max. Drilling Capacity in Concrete
30mm
Optimum Drilling Capacity in Concrete
10-20mm
Max. Drilling Capacity in Wood / Metal
30 / 13mm
No Load Speed
0-1000rpm
Beats Per Minute
0-4480bpm
Weight
3.6kg
( Bare without Battery Pack)
Size( Length x Height)
300mm x 250mm
Vibration Levels
8.5m / s
20V MAX 3” CUT-OFF TOOL
DCS438N
Blade Diameter x Bore Max Blade Thickness Depth of Cut No Load Speed Spindle Thread Weight
Size( Length x Height) Vibration Levels
76mm x 10mm 2.2mm 22mm 20,000rpm M10
1.0kg( Bare without Battery Pack)
208mm x 101mm 3.3 m / s
30
