CIRCULAR SAW BLADES
CIRCULAR SAW BLADES
C4 PREMIUM CARBIDE For extended life and up to 5 regrinds
LASER CUT PLATE For improved balance
RIM EXPANSION SLOTS
HARMONIC SLOTS No blade ringing or scoring
ULTRA-SHARP CARBIDE TEETH Reduces tear out
OPTIMISED GRIND ANGLES Reduces tear out
• Designed for stationary
for professional workshop operation.
• The hallmark EXTREME ® circular saw blades for stationary saws.
• Specially designed to achieve precise cutting and a high
wood, coated and uncoated wood materials and plastic.
TOOTH GEOMETRY
FLAT TOP GRIND( FT) Tooth geometry, in which the cutting edge of the tooth is ground straight and without any inclination. This tooth form is used for longitudinal cuts and for universal applications if high cutting quality is less important.
TRIPLE CHIP GRIND( TCG)
by a slightly higher trapezoidal ground tooth. This higher tooth cuts correspondingly deeper, however, due to its upper edges which are chamfered on both sides, but somewhat narrower than the following
is prevented.
ALTERNATE TOP BEVEL( ATB) Tooth geometry, in which the cutting edges of the teeth are alternately obliquely ground, the angle being from 10 ° to 20 °. For universal use but ideal for cross cuts in hardwood and softwood.
HOLLOW GROUND( HG) Tooth geometry, in which the teeth have been ground to a concave
boards, without the need for scoring.
79
