DeWalt 2026 Catalogue | Page 146

METAL DRILL BITS
LONG LASTING 5 % cobalt content maintains a sharper cutting edge and delivers 4 x longer life( vs HSS-R).
INDUSTRIAL COBALT HSS-CO
SIZE INDICATORS Away from abrasion and, located outside of grip zone, positioning ensures easy readability( from 5mm diameter and up).
NO-WALK TIP The‘ no walk’ tip allows for easier penetration of all surfaces( 5mm and above). Cleaner, more accurate, burr-free holes due to recessed cutting wings.
NO-SLIP SHANK Spin proof 3 sided shaft for optimal grip in drill chuck( diameters 5mm and above only).
STRONG CENTRAL CORE Increasing in thickness towards the chuck, the central core improves fracture stability, particularly in freehand use( 4.8mm diameter and up).
FASTER DRILLING
4 x the penetration speed( vs HSS-R). It also removes debris faster and reduces heat build up.
APPLICATIONS Suitable for portable or stationary drilling of high alloy content steels and metals with a tensile strength up to 1100N / mm 2 e. g. heat and acid proof steel, cast iron, bronze, welded seams, stainless and chrome nickel steels.
FOR USE WITH Corded and cordless drills.
Made in Germany.
PACKS
Cat. No.
Ø mm
Total length mm
Working length mm
Pack Qty.
DT4958-AS
1
34
12
2
DT4959-AS
1.5
40
18
2
DT4900-AS
2
49
24
2
DT4901-AS
2.5
57
30
2
DT4902-AS
3
61
33
2
DT4960-AS
3.3
65
36
2
DT4903-AS
3.5
70
39
2
DT4904-AS
4
75
43
2
DT4961-AS
4.2
75
43
1
DT4905-AS
4.5
80
47
1
DT4906-AS
5
86
52
1
DT4907-AS
5.5
93
57
1
DT4908-AS
6
93
57
1
DT4909-AS
6.5
101
63
1
DT4910-AS
6.8
109
66
1
DT4911-AS
7
109
69
1
DT4962-AS
7.5
109
66
1
DT4912-AS
8
117
75
1
DT4963-AS
8.5
117
75
1
DT4913-AS
9
125
81
1
DT4964-AS
9.5
125
78
1
DT4914-AS
10
133
87
1
DT4965-AS
10.5
133
87
1
DT4915-AS
11
142
94
1
DT4916-AS
12
151
101
1
DT4967-AS
12.5
151
98
1
DT4917-AS
13
151
101
1
SETS
Cat. No.
Description and Contents
Ø mm
DT4968-AS
13 piece of Metal Drills HSS-Co in Plastic Cassete
1.5 / 2 / 2.5 3 / 3.2 / 3.5 4 / 4.5 / 5 / 5.5 6 / 6.5 / 7mm
73
