METAL DRILL BITS
INCREASED DURABILITY AND SPEED Up to 50 % stronger( vs HSS-R). Up to 4X faster drilling( vs HSS-R).
2 HSS-G
NO-WALK TIP Easy starting on curved surfaces. Cleaner, more accurate, burr-free holes due to recessed cutting wings.
NO-SLIP SHANK
in the chuck( diameters 5.0mm and above only).
STRONG CENTRAL CORE Innovative tapered web greatly reduces breakage. Gold ferrous oxide coating prevents overheating for longer bit life.
APPLICATIONS Suitable for portable drilling of steel, alloyed and non-alloyed up to 900 N / mm 2.
FOR USE WITH Corded or cordless drills.
PACKS
Cat. No. Ø mm Total length mm Working length mm Pack Qty.
DT5034-AS
1
34
12
2
DT5035-AS
1.5
40
18
2
DT5036-AS
2
49
24
2
DT5037-AS
2.5
57
30
2
DT5038-AS
3
61
33
2
DT5039-AS
3.2
65
36
2
DT5040-AS
3.3
65
36
2
DT5041-AS
3.5
70
39
2
DT5042-AS
4
75
43
2
DT5063-AS
4.1
75
43
1
DT5043-AS
4.2
75
43
1
DT5044-AS
4.5
80
46
1
DT5045-AS
4.8
86
46
1
DT5046-AS
5
86
46
1
DT5047-AS
5.5
93
57
1
DT5048-AS
6
93
57
1
DT5049-AS
6.5
101
58
1
DT5067-AS
6.8
109
66
1
DT5050-AS
7
109
66
1
DT5051-AS
7.5
109
66
1
DT5052-AS
8
117
72
1
DT5053-AS
8.5
117
72
1
DT5054-AS
9
125
78
1
DT5055-AS
9.5
125
78
1
DT5056-AS
10
133
84
1
DT5057-AS
10.5
133
84
1
DT5058-AS
11
142
91
1
DT5059-AS
11.5
142
91
1
DT5060-AS
12
151
98
1
DT5061-AS
12.5
151
98
1
SETS
Cat. No. Description and Contents Ø mm
DT70710-AS
13 piece set in small ToughCase ™ with EXTREME ® 2 HSS-G Metal Drill Bits
1.5 / 2 / 2.5 3 / 3.2 / 3.5 4 / 4.5 / 5 / 5.5 6 / 6.5 / 7mm
