� ømm
2-STAGE HELIX * Effective dust removal improves drilling performance. |
|
|
|
SDS-PLUS 2 CUTTER |
|
|
WEAR MARK * Indicates that the holes you drill are the diameter you need- ideal for accurate mechanical anchor installation. |
CONCRETE DRILL BITS |
TOUGHCORE ™ * Tapered central core increases stability and durability and increases breakage resistance.
APPLICATIONS Ideal for fast drilling of anchor and plug holes in concrete.
FOR USE WITH SDS-plus hammer drills.
FEATURES TOUGHCORE ™ *
Adds strength and resistance when drilling deep holes with increased side loads.
preventing bit fracturing. WEAR MARK *
ø mm
� ømm
The wear mark is visible- this indicates that the bit is drilling a hole to the required diameter.
The wear mark is no longer visible- the bit has had extensive use, potentially compromising the diameter of the drilled hole.
2 STAGE HELIX *
This accelerates the removal of any concrete mill from the tip, reducing the working temperature and speeding
HELIX up drilling. Made in Germany.
SINGLE PACKS
Cat. No.
Diameter( mm)
Total Length( mm)
Working Length( mm)
2-stage Helix
TOUGHCORE™
WEAR MARK
DT9504-QZ 5 110 50 � 1 DT9505-QZ 5 160 100 � � 1 DT9508-QZ 5.5 110 50 � 1 DT9509-QZ 5.5 160 100 � � 1 DT9514-QZ 6 110 50 � 1 DT9515-QZ 6 160 100 � � 1 DT9519-QZ 6.5 110 50 � 1 DT9520-QZ 6.5 160 100 � � 1 DT9525-QZ 7 160 100 � � 1 DT9528-QZ 8 110 50 � 1 DT9529-QZ 8 160 100 � � 1 DT9530-QZ 8 210 150 � � � 1 DT9536-QZ 9 160 100 � � 1 DT9539-QZ 10 110 50 � 1 DT9540-QZ 10 160 100 � � 1 DT9541-QZ 10 210 150 � � � 1 DT9549-QZ 11 210 150 � � � 1 DT9552-QZ 12 160 110 � � 1 DT9553-QZ 12 200 150 � � � 1 DT9554-QZ 12 260 210 � � � 1 DT9555-QZ 12 300 250 � � � 1 DT9556-QZ 12 350 300 � � � 1 DT9557-QZ 12 450 400 � � � 1 DT9560-QZ 13 160 110 � � 1 DT9561-QZ 13 200 150 � � � 1 DT9562-QZ 13 260 210 � � � 1 DT9566-QZ 14 160 110 � � 1 DT9567-QZ 14 200 150 � � � 1 DT9568-QZ 14 260 210 � � � 1 DT9569-QZ 14 300 250 � � � 1 DT9570-QZ 14 450 400 � � � 1 DT9574-QZ 15 200 150 � � � 1 DT9575-QZ 15 260 210 � � � 1 DT9579-QZ 16 200 150 � � � 1 DT9580-QZ 16 260 210 � � � 1 DT9581-QZ 16 300 250 � � � 1 DT9582-QZ 16 450 400 � � � 1 DT9587-QZ 18 200 150 � � � 1 DT9588-QZ 18 250 200 � � � 1 DT9589-QZ 18 300 250 � � � 1 DT9590-QZ 18 450 400 � � � 1 DT9597-QZ 20 200 150 � � � 1 DT9598-QZ 20 300 250 � � � 1 DT9599-QZ 20 450 400 � � � 1 DT9602-QZ 22 250 200 � � � 1 DT9603-QZ 22 300 250 � � � 1 DT9604-QZ 22 450 400 � � � 1 DT9611-QZ 25 250 200 � � � 1 DT9612-QZ 25 300 250 � � � 1 DT9613-QZ 25 450 400 � � � 1 DT9618-QZ 30 250 200 � 1 DT9619-QZ 30 450 400 � 1 DT9610-QZ 24 450 400 � � � 1
Qty
64
