CONCRETE DRILL BITS
SDS-MAX FULL HEAD CARBIDE BITS
4 FLUTE HELIX Maximises quick debris removal allowing fast drilling and clear holes.
WEAR MARK * Indicates that the holes you drill are the diameter you need- ideal for accurate mechanical anchor installation.
CARBIDE CUTTER Single piece of carbide with four cutting arms, designed to minimise vibration.
IRON BLAST TECHNOLOGY ™ Reduces stress on the bit head and
FEATURES IRON BLAST TECHNOLOGY ™
Reduces stresses in the head of the bit to maximise carbide life.
The surface has increased toughness to withstand demanding environments.
SINGLE PACKS
Cat. No. |
Diameter( mm) |
Total Length( mm) |
Working Length( mm) |
Qty |
DT60810-QZ |
16 |
540 |
400 |
1 |
DT60811-QZ |
18 |
340 |
200 |
1 |
DT60817-QZ |
20 |
540 |
400 |
1 |
DT60833-QZ |
30 |
570 |
450 |
1 |
DT60835-QZ |
32 |
570 |
450 |
1 |
DT60838-QZ |
35 |
570 |
450 |
1 |
WEAR MARK ø mm
� ømm
The wear mark is visible- this indicates that the bit is drilling a hole to the required diameter.
The wear mark is no longer visible- the bit has had extensive use, potentially compromising the diameter of the drilled hole.
4 FLUTE HELIX
between each spiral to rapidly clear the debris. The result is faster drilling and clear holes.
APPLICATIONS For drilling a wide variety of stone, masonry and concrete, including reinforced concrete. Ideal for accurate mechanical anchor installation.
Made in Germany.
FOR USE WITH SDS-max hammer drills.
