LONDON BUILD SHOW PREVIEW
SAFE , DURABLE , ENERGY EFFICIENT ARMATHERM THERMAL BRIDGING SOLUTIONS
Armatherm can help minimise energy loss and significantly improve envelope performance with our family of thermal break products . Our engineers have taken the guesswork out of specifying thermal breaks in the most critical conditions .
ARMATHERM™ FRR STRUCTURAL THERMAL BREAK MATERIAL
Washer and Bushing A thermal break should also be provided at the front side of the bolt head between the steel washer and face of the
exterior steel .
This prevents a thermal bridge through the bolt which would otherwise provide a path for heat flow through the thermal break assembly . Armatherm™ washers and bushings are recommended to eliminate this path and any potential for condensation within the building envelope . Contact us for assistance with your structural design or thermal calculations .
ARMATHERM™ 500 STRUCTURAL THERMAL BREAK MATERIAL
Reducing heat flow within a building ’ s thermal envelope reduces energy consumption as well as potential condensation issues . Thermal bridging through steel and concrete framing can have a significant impact on a building ’ s energy performance . Armatherm™ FRR thermal break material provides low thermal conductivity and high compressive strength . Armatherm™ FRR is made of a reinforced , thermoset resin which has a fire rating of Euroclass B standard and has very limited creep under load making it the ideal material for use in structural thermal break connections .
Applications of Armatherm™ FRR
Reducing heat flow within a building ’ s thermal envelope reduces energy consumption as well as potential condensation issues .
Armatherm™ 500 thermal break material significantly reduces energy lost from thermal bridging in building envelope connections .
• Beam Connections
• Masonry Shelf Angles
• Lintels
• Canopies
• Column Base
• Balconies
• Curtain Wall Mullions
• Rain Screens
• Roof Penetrations
Armatherm™ 500 is a high strength , polyurethane material made in several densities to support a wide range of loading conditions .
Due to it ’ s closed cell structure , it does not absorb water or moisture and has limited creep under continuous load .
Internal Steel Work
Armatherm™ 500 is manufactured in sheets 2000mm x 1000mm x 5mm , 10mm , 12mm , 15mm , 20mm , 25mm , 50mm thick and can be bonded to create 150mm , 200mm and 250mm thicknesses to achieve a specific R value . It can be used anywhere a penetration or transition exists in the building envelope creating a thermal bridge .
External Steel Work
Thermal Break Material
Visit www . armatherm . co . uk for more information T : 01274 591115 | E : info @ armatherm . com
