DBV Rainscreen Facade Product Technical Guide
SYSTEM LOAD TABLES
These tables represent common situation within our offering . Buckling considered in all cases and seismic load not considered . For project specific conditions please contact us for further assistance .
MFT-FOX VI
Base Material : Concrete
Wind load evaluation considering :
Exposure : C
Risk Cat .: II
Height : 100 ft ( 30.48 m )
Zone : W4
Wind speed : ≤95 mph ( 42.47 m / s )
Example according to ASCE 7-16 Wind Map :
Wind load : 27 lb / ft ² (± 1.28 kN / m ²)
Seattle , Portland , Sacramento , LA , SF , SD , Las Vegas , Dallas
1-Rail Vertical - 3.1-10.2 lb / ft ² ( 15-50 kg / m ²) Panel
Brackets ( 1.5 " - 5.5 " / 40-140mm )
L-rails
T-rails
Screws
Base Fastener
Medium
Large
2-1 / 2 " x2 " x0.1 "
2-1 / 2 " x4 " x0.1 "
S-AD 01S 5.5x19
KB-TZ2 3 / 8x3
Metric
[ pieces / m ²]
[ pieces / m ²]
[ m / m ²]
[ m / m ²]
[ pieces / m ²]
[ pieces / m ²]
0.45
0.23
0.45
0.23
1.81
0.91
Imperial
[ pieces / ft ²]
[ pieces / ft ²]
[ ft / ft ²]
[ ft / ft ²]
[ pieces / ft ²]
[ pieces / ft ²]
0.04
0.02
1.49
0.74
0.17
0.08
Wind speed : ≤110 mph ( 49.17 m / s )
Example according to ASCE 7-16 Wind Map :
Wind load : 36 lb / ft ² (± 1.28 kN / m ²)
Boston , NY , NJ , Philladelphia , DC , Chicago
1-Rail Vertical - 5.3-10.2 lb / ft ² ( 26-50 kg / m ²) Panel
Brackets ( 1.5 " - 5.5 " / 40-140mm )
L-rails
T-rails
Screws
Base Fastener
Medium
Large
2-1 / 2 " x2 " x0.1 "
2-1 / 2 " x4 " x0.1 "
S-AD 01S 5.5x19
KB-TZ2 3 / 8x3
Metric
[ pieces / m ²]
[ pieces / m ²]
[ m / m ²]
[ m / m ²]
[ pieces / m ²]
[ pieces / m ²]
0.63
0.32
0.63
0.32
2.54
1.27
Imperial
[ pieces / ft ²]
[ pieces / ft ²]
[ ft / ft ²]
[ ft / ft ²]
[ pieces / ft ²]
[ pieces / ft ²]
0.06
0.03
2.08
1.04
0.24
0.12
