DBV Rainscreen Facade Product Technical Guide
SYSTEM LOAD TABLES
These tables represent common situation within our offering . Buckling considered in all cases and seismic load not considered . For project specific conditions please contact us for further assistance .
MFT-FOX VI
Base Material : Steel studs Distance Between Steel Studs : 16 " = 406.4mm Thickness of steel studs : 16 gauge = 1.29mm
Wind load evaluation considering :
Exposure : C
Risk Cat .: II
Height : 100 ft ( 30.48 m )
Zone : W4
Wind speed : ≤95 mph ( 42.47 m / s )
Example according to ASCE 7-16 Wind Map :
Wind load : 27 lb / ft ² (± 1.28 kN / m ²)
Seattle , Portland , Sacramento , LA , SF , SD , Las Vegas , Dallas
1-Rail Vertical - 0-2.9 lb / ft ² ( 0-14 kg / m ²) Panel
Brackets
( 1.5 " - 5.5 " / 40-140mm )
L-rails
T-rails
Screws
Base Fastener
Medium
2-1 / 2 " x2 " x0.1 "
2-1 / 2 " x4 " x0.1 "
S-AD 01S 5.5x19
S-MD 51S 5.5x50
Metric
[ pieces / m ²]
[ m / m ²]
[ m / m ²]
[ pieces / m ²]
[ pieces / m ²]
1.64
1.31
0.33
3.28
3.28
Imperial
[ pieces / ft ²]
[ ft / ft ²]
[ ft / ft ²]
[ pieces / ft ²]
[ pieces / ft ²]
0.15
4.30
1.08
0.30
0.30
Wind speed : ≤110 mph ( 49.17 m / s )
Example according to ASCE 7-16 Wind Map :
Wind load : 36 lb / ft ² (± 1.28 kN / m ²)
Boston , NY , NJ , Philladelphia , DC , Chicago
1-Rail Vertical - 0-5.1 lb / ft ² ( 0-25 kg / m ²) Panel
Brackets
( 1.5 " - 5.5 " / 40-140mm )
L-rails
T-rails
Screws
Base Fastener
Medium
2-1 / 2 " x2 " x0.1 "
2-1 / 2 " x4 " x0.1 "
S-AD 01S 5.5x19
S-MD 51S 5.5x50
Metric
[ pieces / m ²]
[ m / m ²]
[ m / m ²]
[ pieces / m ²]
[ pieces / m ²]
2.19
1.31
0.33
4.37
4.37
Imperial
[ pieces / ft ²]
[ ft / ft ²]
[ ft / ft ²]
[ pieces / ft ²]
[ pieces / ft ²]
0.20
4.30
1.08
0.41
0.41
