DBV Rainscreen Facade Product Technical Guide
VERTICAL RAIL FASTENERS
Hilti offers two vertical systems :
• 1-Rail system
• 2-Rail system
1-Rail system 2-Rail system
Vertical
Horizontal
• Vertical bracket in line with the vertical rail .
• Vertical bracket in line with the vertical rail for the 1 st layer and the 2 nd layer in horizontal alignment ( 2 nd layer rails with slotted holes for expansion compensation .)
