622
Ø 24 1/2"
690
27 1/4"
690
27 1/4"
883
34 3/4"
883
34 3/4"
LIFT AND TURN
LID TO EMPTY
318
12 1/2"
CENTER ARM
162
6 1/4"
708
27 3/4"
856
33 3/4"
708
27 3/4"
856
33 3/4"
1035
40 3/4"
454
17 3/4"
454
17 3/4"
VERTICAL STRAP
BASKET INSERT
1232
48 1/2"
GLIDE FOR FREESTANDING UNIT.
REMOVE TO SURFACE MOUNT.
(4) Ø 3/8 [10] NON-CORROSIVE BOLTS
RECOMMENDED FOR ANCHORING,
PROVIDED BY OTHERS.
1842
72 1/2"
GLIDE FOR FREESTANDING UNIT.
REMOVE TO SURFACE MOUNT.
(4) Ø 3/8 [10] NON-CORROSIVE BOLTS
RECOMMENDED FOR ANCHORING,
PROVIDED BY OTHERS.
FREESTANDING OR SURFACE
MOUNT OPTIONS. NON-CORROSIVE
ANCHORING HARDWARE SUPPLIED
BY OTHERS. (4) Ø7/16" [Ø11] MOUNTING HOLES.
©
©
1
©
BENCH DETAIL
2
™
®
EDGE OF
PAVING
476
648
18 3/4" 25 1/2"
12"
Ø1 1/2"[38]
TUBING
629
Ø24 3/4"
692
27 1/4"
714
28 1/4"
451
17 3/4"
106
4 1/4"
GRADE
GLIDE FOR FREESTANDING UNIT.
REMOVE TO SURFACE MOUNT.
(4) Ø 3/8 [10] NON-CORROSIVE BOLTS
RECOMMENDED FOR ANCHORING,
PROVIDED BY OTHERS.
1842
72 1/2"
152
6"
EMBEDDED
102
4"
©
3
BIKE RACK DETAIL
©
4
BACKLESS BENCH DETAIL
TRASH RECEPTACLE DETAIL
