Cold Link Africa September 2022 | Page 36

PRODUCTS
INCORPORATING COLD CHAIN

Frost free cold stores

Ice builds up on cold store ceilings , walls , floors , and packaging and has the potential to cause unsafe working conditions . Reduced visibility from fog increases loading and unloading times . The build-up of ice / frost on packaging can further result in failure affecting product quality and prevent scan functions .
Munters IceDry , distributed by SMAC Enterprises , alleviates these issues by dehumidifying the incoming air from inside the cold store and removing high moisture levels , which at sub-zero temperatures quickly turns to frost / ice . A dehumidifier inside the cold store produces a frost-free environment . Accumulated ice and frost will gradually evaporate until the store is completely free from ice and frost .
IceDry is the only dehumidifier developed especially for installation inside a cold store .
Key features :
• Specially developed for cold store installation
• Automatic defrosting function
• Increased efficiency of evaporators
• Reduced need for defrosting cold store
• No ice on products , secures the quality of frozen goods
• Less mechanical failures , reduced maintenance costs
• An airlock is no longer needed
• Airflow 1400m3 / h / 3000m3 / h
For more information : willie @ airtreatment . co . za

Shortest ride-on truck in its class

The powerful ERE 2i electric low lift pallet truck is exceptional when loading and unloading HGVs as well as working in confined warehouse environments .
Compact and sturdy design means it is the perfect choice for demanding operations in the trans-shipment warehouse .
A powerful drive motor with strong acceleration and agile handling ensures maximum efficiency , while the compact design of the ERE 225i enables intuitive operation with optimum visibility of the goods .
Optional platform variants and variable battery capacities offer the greatest flexibility for every customer need . Maximum safety and comfort when working are provided by the robust frame with high side protection and the spacious stand-on platform .
Other sophisticated functions such as HGV detection with

Any trailer , any mission

The VT180 by Transfrig is a single temperature cooling slim line trailer refrigeration unit for insulated trailers , designed to operate in the most robust conditions .
A speed-controlled diesel engine , variable speed brushless condenser and evaporator fans and an electronic expansion valve provide high levels of efficiency with low noise depending on engine load .
Accurate temperature control and balanced air distribution in the load body ensures the highest product quality with consistent performance .
Benefits :
• Reliable technology
• Fast pull down and accurate temperature control due to electronic expansion valve
• Robust design and high quality components
• Low fuel consumption due to speed-controlled engine .
Low maintenance
• Long Life components
• Beltless energy transmission
• Easy access to components and serviceable areas .
Intelligent Control
• Convenient and robust control panel
• User friendly
• Diagnostics available via USB
• Telematics
• Access to PLC and unit data via Bluetooth application .
Emissions reduction
• Reduced emissions due to speed-controlled diesel engines and fans . automatic speed reduction and illumination of the HGV make working safer and more effective in every situation .
Features :
• Advanced drive technology
• Fast and safe driving on ramps
• Operator-friendly operating concept
• Predictive assistance systems
• Flexible operator platform and variable fork length
For more information , contact + 27 ( 0 ) 010 596 8460
Technical data
• Cooling capacity @ 30 ° C ambient ( W ) / R404a 0 ° C – -20 ° C
• Fan type Brushless DC , Axial
• Air volume flow ( m3 / h ) 10200
• Weight ( kg ) 880
For more information , contact + 27 ( 0 ) 11 608 0462

New capacity regulation technology

The flexxCO2NTROL technology is a new , efficient compressor capacity regulator that allows the capacity of trans-critical BOCK CO 2 compressors to be adjusted to the current capacity requirements of the system .
Regulation covers a range between 100 percent and 25 percent capacity , depending on the operating conditions . This ensures great economic and technical advantages , especially in application areas with highly fluctuating capacity requirements .
• Start / stop operation of compressors is minimised
• System includes a digital capacity regulation , which enables an almost stepless adjustment at high part load requirements by means of modulating control of the solenoid valves with high switching frequency via an external system controller .
• Valve control can usually

NH 3 sensor to meet plant standards

The Evikon ammonia detectortransmitter E2638-NH3-E , distributed to the Southern African region by Keystar Industries , is a member of new PluraSens family of multifunctional measurement instruments .
This instrument is intended for leakage control in refrigeration facilities , warehouses , etc . It is not recommended to use the device in spaces with constantly high ammonia concentration .
The instrument utilises a fully calibrated and temperature compensated electrochemical gas sensor be realised with existing system controllers .
• High economy and system efficiency proves an attractive alternative to capacity regulation of CO2 compressors with simple compressor start-stop or solutions with frequency inverters .
• Regulator can be used as an accessory component for all transcritical BOCK CO2 4- and 6-cylinder compressors of the series HGX24 CO2 T , HGX34 CO2 T , HGX46 CO2 T .
For more information , contact + 27 ( 0 ) 71 525 3089
with excellent repeatability , stability , and long lifespan .
Two relays with closing contact may be used for remote signalling or concentration control . Two alarm set-points are user settable .
Two analog outputs and RS485 digital interface with industry standard Modbus RTU protocol can be used to connect the detector to safety or building automation systems .
This product includes industrial IP65 housing and can be attached or remote sensor configured .
Sensors in the range for the detection of other gasses include :
• CO 2
( carbon dioxide )
• CO ( carbon monoxide )
• C 2
H 4
( ethylene )
• CH 4
( methane )
• HFC ' s ( freons )
• R290 ( propane )
• Water ( humidity )
For more information , call + 27 ( 0 ) 11 205 0639 or + 27 ( 0 ) 86 111 4768

36 www . coldlinkafrica . co . za COLD LINK AFRICA • September 2022
