INCORPORATING COLD CHAIN
PROJECT refrigeration energy consumption, alongside an increase in storage volume of over 150 %.( Refer to table 1)
Old Cold Store
New Cold Store
Floor Area m ² 4 822 2 950-39 %
Difference
Volume m ³ 15 375 39 600 + 158 %
Monthly Energy Consumption
Table 1.
MWh 122 80-34 %
Following the commissioning phase, Energy Partners ensures continuous performance monitoring and reporting of the system. This comprehensive approach encompasses performance metrics such as the efficiency, or Coefficient of Performance( COP), utilisation rates and system stability, all aimed at minimising the total lifecycle cost. Additionally, critical process parameters, including glycol and room temperatures, are systematically tracked, reported and analysed.
To further enhance operational reliability, Lactalis benefits from Energy Partners ' 24 / 7 remote plant monitoring service. This service promptly identifies, reports and addresses alarms and alerts, ensuring early detection and resolution of potential issues.
“ Working within existing structures presented unique challenges but was overcome by Morne de Kock, Lactalis project manager, being on site every day. His personal involvement in the removal of old equipment and the required diversion of electrical and water services proved invaluable. During the entire construction Morne was also on site daily and any unexpected problems could be resolved promptly,” commented Hougaard Langeveldt, head: Energy Partners Engineering. CLA
CO2 package with two BITZER compressors for the low temperature store.
The two directly coupled compressors in the foreground were of new supply and the belt driven in the background from a previous plant. All cylinder heads are water cooled.
Image provided by John Ackerman Image provided by John Ackerman
Project: LACTALIS PAROW DC
Plant Owner:
LACTALIS Group Professional team and equipment suppliers Consultants and project management Plant performance and energy monitoring
CO2 package
Insulated panels Docking cubicles Blower coils Ammonia compressors Racking
Energy Partners Engineering
Energy Partners Asset Management
Energy Partners Refrigeration
I D S
Unicape Heating Centre MYCOM Dexion
The low temperature cold store for ice cream is connected to the CO2 package.
COLD LINK AFRICA • October 2025 www. coldlinkafrica. co. za 27
Image provided by John Ackerman
