INCORPORATING COLD CHAIN
PRODUCTS
GEA BluX
Sustainable technology is becoming increasingly important for the operation of industrial and commercial refrigeration systems . Growing public awareness , the strive for fossil independence and advancing climate and environmental protection standards are promoting cleaner , ecofriendly sources of energy . This makes systems using the power of alternative sources , such as natural refrigerants with its outstanding characteristics , increasingly attractive . GEA BluX has been developed for ammonia ( R717 ) – the climate-friendly , future-proof and highly efficient natural refrigerant for sustainable refrigeration solutions – in compliance with the F-gas regulations . It plays a key role in supplying people around the world with pleasant living and working environments , fresh food and beverages , and further goods – such as pharmaceuticals .
Air conditioning of commercial , residential and public buildings GEA BluX is an ideal chiller for air conditioning systems . Almost every type of modern commercial , residential or public building needs systems to ensure a comfortable air temperature and healthy living conditions . All technology solutions for this area of application must meet special safety standards . GEA BluX is distinguished by its sophisticated design that minimises the risk of gas emissions or technical defects in order to safeguard the well-being of people in every location .
Industrial refrigeration for the food , beverage and process industry Modern , fast transportation networks and sophisticated refrigeration technologies make sensitive fresh foods from all over
E . C . A . Solenoid Valves
E . C . A . Solenoid Valves are designed to be installed on refrigeration and air conditioning systems . Solenoid valves are compatible with all commonly used refrigerants like CFC , HFC , HCFC and
CO 2
( except NH 3
).
Valves can be easily soldered to the system with copper tube connections . Every product is 100 % tested for external leakages with a helium detector . Coil assembly with additional customers ensures corrosion resistance and long life cycle .
For more information , contact + 27 ( 10 ) 271 0686
the world available year-round . Strict temperature control and careful handling are crucial for maintaining their quality and to meet official requirements . The new GEA BluX chiller has been designed to offer compact solutions to safely maintain the cold chain .
• Processing of vegetables , fruits , dairy products , beverages and convenience food
• Cold storage and distribution centers
Highlights and technical features :
• Ammonia ( R717 ) chillers – safely futureproof in compliance with the F-gas regulation – efficient in compliance with the Eco-Design guideline For air conditioning and industrial refrigeration
• For air conditioning and industrial refrigeration
• For secondary refrigerant outlet temperatures from -15 to + 18 ° C
• Smallest refrigerant charge 40 – 50 g / kW
• Increased flexibility , redundancy and optimal for peak-load and efficient partload operating demands – new BluX duo version available with the new GEA CompaX compressor models 350 and 400
• Alternative design options
For more information , contact + 27 ( 21 ) 555 9000
Rivacold CI GmbH
Future-proof refrigeration technology for commercial cooling . Rivacold CI GmbH offers liquid coolers from the Champ CH series with the natural refrigerant propane ( R290 ). The devices were presented to the general public for the first time at the international Chillventa trade fair in Nuremberg . Five models for normal cooling cover the power range between 8 and 20 kW . In parallel operation , up to four devices can be combined in master-slave mode . The range of systems is rounded off by a hydraulic module with a water tank , fittings and speed-controlled consumer pumps in the three tank sizes of 200 , 300 and 600 litres .
The new Champ CH device generation combines various measures to increase cooling and energy efficiency . These include electronically controlled bypass and expansion valves in conjunction with an optimised plate evaporator , highly efficient accumulator charging pumps and condenser fans with EC motors , which all-in-all exceed the requirements of the Ecodesign Regulation . Planning , assembly and operation are greatly simplified with a pre-integrated pump unit for brine circulation and a preconfigured operating mode plus remote / control via Rivacold ' s MyVision platform .
For more information , contact + 33 ( 4 ) 73 14 55 50
The Daikin R-32 VRV Chiller – for the first time in a split version
The Daikin R-32 VRV chiller series is expanded with new models in split version . This supplements Daikin ' s broad product portfolio of VRV chillers with the more climate-friendly refrigerant R-32 .
Efficient heating and cooling The inverter-controlled heat pump is available in the power classes 21-64 kW and can therefore be used for heating and cooling in buildings of different sizes . The Daikin R-32 VRV chiller reacts flexibly to different cooling and heating requirements with flow temperatures of + 60 ° C when heating or -15 ° C in cooling mode . With a SEER ( seasonal cooling efficiency ) that goes up to 5.7 and a SCOP ( seasonal heating efficiency / seasonal performance
factor ) of up to 4.2 , this heat pump works particularly efficiently and also ensures low running costs . The compact design of the devices and the integrated safety system enable the heat pump to be installed even in small rooms .
For more information , contact + 27 ( 0 ) 11 997 4400
