Most car manufacturers opted for R-1234yf |
The sector that has had most difficulty |
strong competition between systems |
required residential air-conditioners to |
|
and , although implementation was slightly delayed beyond the initial date of 2013 in the MAC directive , this accounts for most car air-conditioning systems in the global market at present . These wrong turns are unfortunate because for many years there has been a substantial and extremely safe market in retrofit fluids for car airconditioners in hot climates .
It was estimated back in the early 2000s , before the moves to identify the replacement for R-134a really got going , that over 250 000 motor vehicles in the southern states of the US had been switched by amateurs from R-12 to some variant of R-290 , often sold under a brand name such as R-12a which hid the fact that it was a flammable hydrocarbon . This was usually done to improve the performance of the system in pulling down to temperature from a hot start and despite the lack of training and lack of awareness there were no press reports of accidents , injuries or
|
up to now in adapting to the changes in refrigerant acceptability is the market for split and multi-split air-conditioners . These devices were originally developed in Japan in the 1960s and have become common all over the world , particularly in the addition of air-conditioning to older buildings that are not suitable for the installation of air ducts or large water pipes . Originally designed for R-12 and R-22 , they transitioned to R-407C in the 1990s , then R-410A and more recently R-32 . The move to R-32 has required a substantial rethink on system safety and flammability as well as a significant increase in design pressure .
It also required significant technical development to achieve acceptable efficiency levels as the critical temperature of R-32 , at 78 ° C , is much lower than R-12 or R-22 , which are 112 ° C and 96 ° C respectively . Significant effort has also been invested in the development of air conditioners using hydrocarbons as refrigerants but their widespread adoption
|
using ammonia in screw or reciprocating compressors and systems using HFO- 1234ze ( E ) in centrifugal compressors . More recently large systems have been engineered using carbon dioxide in a combined compressor-expander but these are not yet widely available and their efficiency has not been proven . There has been some limited use of air-source heat pumps with HFCs , even up to several megawatt capacity , but these are also not common . In smaller commercial and domestic heat pumps the trend tends to follow the split air-conditioning market , even where the heat pump is only for hot water heating in central heating systems . At present HFC-410A and HFC32 are the most common refrigerants with some limited use of hydrocarbons in smaller systems . Carbon dioxide has been widely used in heat pump water heaters used to heat mains water to above 60 ° C . It is difficult to make those systems efficient for heating recirculated water for central |
have a seasonal energy efficiency ratio
( SEER ) of at least 9 . SEER is the ratio of the
annual cooling effect achieved ( measured
in BTU ) to the electrical energy used over
the year ( measured in Wh ). By 2015 the
legal minimum SEER had increased to 14
in hot climates and 13 in the rest of the US ,
meaning that on a like for like basis the
baseline efficiency has improved by 30 %.
However , there are models on the market
with SEER in the 20s or even 30s which
would reduce energy use to about 30 % of
the 1992 minimum standard . In other sectors
there have been similar improvements in
efficiency , for example in water chillers ,
but it is evident across many sectors that
operating efficiency often falls far short of
the design ideal . In a survey of European
cold storage conducted about ten years
ago it was noted that the average energy
consumption across several hundred
locations was about ten times higher than
what is best practice performance , so
clearly there is a significant opportunity for
improvement .
|
deaths caused by this switch . This doesn ’ t mean that the process was trouble-free , only that alongside the high number of road traffic fatalities the change was not noticeable and was therefore acceptable to the general public . |
is hampered by legitimate safety concerns over their higher flammability .
Heat pumps come in a wide range of sizes and need to be considered sector by sector . The district heating market for water-source heat pumps has seen
|
heating because the return water temperature is usually not low enough .
Over the last 30 years some significant advances have been made in efficiency terms , but there is still room for improvement . For example , in the US a law entered into force in 1992 that
|
5 . WHAT NEEDS TO HAPPEN NEXT
The next steps in the journey do not depend
so much on refrigerant choice , but rather
on the transition that is already ongoing in
the sourcing of power to run the systems .
|
