INCORPORATING COLD CHAIN

PRODUCTS

Smart trailers making transport more efficient

Truck and trailer body building company Serco has introduced a smart trailer system developed in partnership with South African technology specialists Ikhaya Automation .

Features include real time on-board weighing , making it possible for operators to identify axle overloads and thus prevent possible fines and delays . The smart system sends an alarm when axle limits have been exceeded , enabling adjustments to be made .

Integrating with the trailer ’ s EBS system , it records mileage and sends alerts when the vehicle is due to be serviced . By monitoring supply air pressure to the braking system , leaks and damaged airbags can be detected , contributing to a safe and efficient running trailer .

Door opening sensors and temperature probes can be added and these

Plate heat exchanger with local content

ProTherm Systems supplies and manufactures the Thermowave plate heat exchanger range , among other solutions .

Product features :

• Size range : wide size range from small to large ( up to 1 500m3 / h ).

• Plate types : power-line plates for high thermal performance and standardline plates which are relatively dirt resistant .

• Plate materials : various materials options including stainless steel grades 304 , 316 , SMO254 , Alloy 825 and titanium .

• Gaskets : clip in type available in NBR , HNBR , EPDM , Chloroprene & FPM ( Viton ).

• Frames : rated for operation at pressures up to 25 Bar and available in carbon steel painted or glass flake coated or in stainless steel , cladded for larger units . Option for frames to be stainless steel fitted .

• Local content : while pressed plates and moulded gaskets are of German origin , Protherm Systems manufactures all other components , such as frame plates . All assembly and testing of heat exchangers occurs at our premises .

integrate with auxiliary systems such as tyre pressure monitoring and GPS tracking to enhance the performance of a transporter ’ s fleet management system .

Ensuring a trailer is running optimally using smart technology helps reduce running costs and minimise breakdowns while improving vehicle safety .

For more information , contact + 27 ( 0 ) 31 508 1000

• Spares & service : Protherm Systems carries an extensive stock of plates and gaskets locally . A service crew is available for cleaning and maintenance of plate heat exchangers ( all makes ).

• Technical support : Specialist heat exchanger & process engineers available .

For more information , contact + 27 ( 0 ) 11 786-0652

Small robot , top performance

The smallest palletising robot in the Yaskawa Motoman PL-series offers top performance with its 5 axes for box , carton and pack palletising in end-of-line packaging and logistics applications .

The extended vertical reach of 3291 mm ensures high palletising heights , in combination with its horizontal reach of 2061 mm , this enables a wide range of applications .

The compact Motoman PL80 guarantees high palletising loads of up to 80kg and impresses with its low overall height , slim design and small footprint . The Motoman PL80 is equipped with the latest Yaskawa Sigma7 drive technology and the compact YRC1000 high performance controller .

Key benefits

• New Sigma7 servo motors –> high accelerations , speed , energy efficiency

• High payload : max . 80 kg

• Large working range : 2061mm

• Compact and slim design

• Advanced functional safety ( FSU ) with YRC1000 controller

• Programmable by PLC function blocks via MotoLogix software interface

• Dust and liquid proof wrist design ( IP54 / 67 )

• Mounting option : Floor

The series has a payload range from 80kg to 800kg . View spec sheets online .

For more information , contact + 27 ( 0 ) 11 608 3182

CAREL @ Chillventa : improving refrigeration system performance

At the recent Chillventa ( Nuremberg , 11-13 October 2022 ) CAREL presented its innovative solutions for increasing the energy efficiency and improving the performance of refrigeration systems .

In refrigeration systems , more aware technological choices can have a significant impact on energy consumption and food storage , and therefore become a positive factor for change in this crucial sector . In order to support the drive to reduce energy consumption , guaranteeing complete management of refrigeration systems with the focus on energy efficiency and performance optimisation , CAREL has developed solutions capable of ensuring both the highest quality food preservation and ease of use , from installation through to everyday operation of the systems by the user .

CAREL ’ s proposal for centralised systems is based on DC technology applied to both condensing units ( Hecu solution ) and units with rotary compressors ( Multi DC solution ). Synchronised operation of the variablespeed BLDC compressor with the inverter and the electronic valve allows continuous modulation of performance , meeting the load requirements of every refrigeration

unit while adapting to specific daily and seasonal variability . For commercial refrigeration applications , complete unit management is ensured by the MPX and Heos solutions , electronic controllers developed to guarantee stable unit control temperature and integrated operation of modulating devices . All these controllers offer a high level of certification , making them suitable for incorporation into units that use flammable refrigerants ( A3 ). Embedded NFC and Bluetooth connectivity respond to the need for extended and simplified usability , through the use of apps developed specifically for interaction with the unit .

For more information , contact + 27 ( 0 ) 11 805 1090
