PRODUCTS
Thermal barrier coating
Ceratech Coatings offers a thermal heat barrier with great long-lasting results . The technology pioneered by the space agency NASA can be a significant add-on to the perishable food storage , shipping container and transport sectors of the cold chain .
This solution aids in reducing electricity and diesel consumption tremendously and can further reduce
The smart way of monitoring flow
wastage as global warning becomes more and more relevant . Product benefits :
• Reduces interior heat by up to 45 %
• Save electricity by requiring less air conditioning and refrigeration capacity
• Offers indoor comfort in hot weather when applied to roofs
• Stops thermal ageing by reducing heat load
• Insulation at a fraction of the cost of other solutions
• Prevents rust , eliminates blistering , peeling and cracking
• Eco friendly solution
• Quick and easy low-cost application
For more information , contact : + 27 ( 0 ) 83 262 1244 or visit www . ceratech . co . za .
Instrotech Kobold KAL-D flowmeters have an integrated microcontroller that allows users to optimally adapt the device to their individual process conditions . Its intelligent compensation function ensures stable switching points , even during significant temperature fluctuations .
The electronic flow monitor model works according to the calorimetric principle , continuously monitoring water-based liquids . The sensor tip is heated to a few degrees above the temperature of the flowing medium . When the medium flows , heat generated in the probe is dissipated by the medium . This cooling sequence precisely measures the flow velocity .
Key features :
• Switching range : 0.04 m / s ... 2 m / s ( liquids ); 1 ... 20 m / s ( air )
• Connections : G ¼ , G ½ , ¼ " NPT , ½ " NPT , M12 x 1
• Material : stainless steel
• Max pressure : 100 bar process pressure
• Max temperature : 120 ° C process temperature
• Repeatability : ± 2 %
• Wide range of process connections ; easy to customise , commission and install
• No moving parts
For more information , contact + 27 ( 0 ) 10 595 1831 .
Complete management of process chillers
INCORPORATING COLD CHAIN
Advancing competitive edge for biotech and pharma
Alfa Laval UltraPure products boost pharma and biotech process efficiency , productivity and end-product quality .
The new LKH Prime 10 UltraPure self-priming pump and upgraded LeviMag UltraPure magnetic mixers also reduce total cost of ownership while ensuring more responsible use of resources for sterile processing applications .
Advantages include :
• Duties up to 35 m ³/ h , it is primarily engineered for Cleaning-in-Place ( CIP ) return , but also transfers product in sterile processes .
• Up to 60 % more energy savings than liquid ring pumps and up to 25 % more than other airscrew pumps .
The Carel range for the management of chillers has been enriched with µ Chiller Process , the first compact and cost-effective controller on the market for complete management of process chillers with on-off and variablecapacity BLDC compressors . µ Chiller Process covers most process applications without the need for modifications or the addition of external devices . The solution is completed by innovative connectivity features .
The µ Chiller Process controller combines the reliability of traditional design
• A fully CIPable , EHEDGcertified hygienic design .
• 80 % lower noise levels for a better working environment .
• Easy maintenance and streamlined spare parts inventory due to the common LKH platform .
• Increased yield due to gentle product treatment and the ability to mix to the last drop , with optimised impeller geometry and 100 % levitated design .
• Highest hygiene possible as the unique levitating
with innovative elements for high efficiency and connectivity so as to comply with regulations and respond to the demands of end users .
The compact dimensions of the chillers that offer in-line cooling services in production plants means that all of the components must be likewise compact . In the same way , greater integration of functions into the controller itself minimises the need for additional components outside of the unit .
The availability of serial impeller design eliminates product contamination from wear particles and secures full cleanability .
• Sustainable , low-cost operation : 40 % higher pumping capacity and reduced energy costs and
CO 2 emissions due to flow optimised impellers .
For more information , contact : + 27 ( 0 ) 11 230 3600 .
ports , connectivity via Bluetooth with smartphones using the Carel Applica app or via computer , offer various methods of interaction between the unit and the end user and / or manufacturer .
For more information , contact : + 27 ( 0 ) 11 805 1558 .
DO YOU HAVE AN INNOVATIVE AND RELEVANT PRODUCT YOU
WOULD LIKE FEATURED ? LET US KNOW ... IT ' S FREE Contact + 27 ( 0 ) 11 579 4950 or Email : benjamin @ interactmedia . co . za
Fresh food , with minimum energy
Danfoss is empowering food retailers to make predictive maintenance a reality today and has strengthened their Alsense IoT services with a holistic store-level software suite , moving store maintenance from reactive to proactive . This enables food retailers to prioritise and reduce their maintenance efforts across stores and critical events .
Combining the Smart Refrigeration Solution with the existing Alsense portfolio , accelerates their ambition of meeting food retail customers ’ needs for optimising and proactively maintaining a high store performance . This solution goes beyond the traditional monitoring systems that are primarily providing alarms and data overviews . It identifies operating issues , such as compressor failure or coil icing , and provides hands-on guidance to fix them .
The Smart Refrigeration Solution software was developed based on customer requirements gathered from leading food retailers who were looking to save money by reducing energy spend and improving performance of their refrigeration system .
For more information , go to : alsense . danfoss . com .
