PROJECT
INCORPORATING COLD CHAIN
Refrigeration system details for the Port Elizabeth processing facility
Site Information
• Description: New CO 2 refrigeration booster system
• Conditions: 36 ° C ambient; 60m above sea level
• 3 X 16 compressor R744 booster racks with parallel compression.
SYSTEM BREAKDOWN
This comprehensive breakdown clearly explains the refrigeration system designed for the Port Elizabeth processing facility. We believe this system will provide optimal performance, ensuring the site ' s refrigeration needs are met with precision and reliability. CLA
The building under construction.
Image supplied by CCS
© Cold Link Africa
A view of the plantroom.
All PRVs are piped to a common header and then piped outside.
© Cold Link Africa
© Cold Link Africa
1 X VSD for MT Compressor 1, 1 X VSD for IT Compressor
Racking being installed.
Image supplied by CCS
26 www. coldlinkafrica. co. za COLD LINK AFRICA • June 2025
