COMPLEX CURVED FAÇADE ON HAMBURG’ S NEW STUNNING CONCERT HALL
»»
LOCATED ON THE ELBE RIVER, ON the western tip of the HafenCity in Hamburg, Germany, the Elbphilharmonie is one of the largest and most acoustically advanced concert halls in the world and an outstanding example of modern architecture.
The Elbphilharmonie boasts stunning architecture in the mixed-used facility. Designed by Herzog & de Meuron, the building is not just a site for music; it is a fully-fledged residential and cultural complex. The 108-metre-high building, which officially opened in January 2017, accommodates a philharmonic hall, a chamber music hall, restaurants, bars, a terrace with panoramic views of Hamburg.
The design of the new glass building resembles a hoisted sail or water wave. Extruded from the shape of the original Kaispeicher warehouse that supports it, the new glass building is identical in ground plan with the brick block of the older building, above which it rises. However, at the top and bottom, the new structure takes a very different design from the quiet, plain shape of the warehouse below.
Complex curved glass façade the new building’ s stunning 21,800m2 glass façade consists in part( approx. 5,000m2) of curved glass that transforms the structure into an enormous quartz crystal, whose appearance continually changes as it catches the reflections of the sky, the water and the city lights.
Josef Gartner GmbH was responsible for developing the glass façade. It is comprised of both flat and curved insulating glass units( IGUs) for the windows, as well as triple laminated curved single glazing for the loggias( covered exterior galleries).
One of the challenges was developing the curved glass elements of the façade. Up to that time, nobody has ever bent glass panes of that complex 3-D-geometry.
The next challenge was to maintain the functions of the different coatings of the glass during the manufacturing process. The glazing of the façade consists of a low-E coating, a solar control coating, chrome mirror dots and a ceramic silk-screen pattern. The solar control coating and the chrome dots were vital in achieving the customers’ performance requirements.
