MD3020
4 HEAD HORIZONTAL QUAD WELDER
SEAMLESS STANDARD ALI CLAD
90 ̊ CORNER WELD
FOOTPRINT : 6.5m x 5.12m
BENEFITS
Kaban MD 3020 Seamless Welder is without doubt the finest way of producing the perfect 90 degree corner detail . Positives are many , ranging from its outstanding visual appearance , structural / water ingress integrity and speed of manufacture ( machine cycle time , just 90 seconds ).
This alone , places SEAMLESS and STANDARD welding technology well ahead of any other types of jointing methods .
From a production stance – machine loading can be maximised between Seamless and Standard works .
KABAN : THE FUTURE TODAY
FEATURES
• Kaban MD 3020 , much more than an efficient SEAMLESS or ALI CLAD COMPOSITE welder .
• Switch seamlessly between SEAMLESS and STANDARD WELDING with 0.2 mm weld sprue .
• When STANDARD WELDING , Shadow grooving knives ( width and depth ) can be matched perfectly to cruciform and transom / mullion grooving made on other production machines .
• Single person operation .
• Comprehensive UK Weld Break Testing programme successfully undertaken and completed in conjunction with leading system house , testing facility .
• Tolerates cutting angle discrepancies up to 0.5 degrees .
• Tolerates cut length discrepancies up to + 2 mm
• Finished frame accuracy to within 0.1 mm on width and height .
• As with ALL Kaban machines , including their superb Kaban FA 3010 UPVC Cut and Prep Machining Centre – maintenance and the replacement of serviceable items can be made via the owner / operator .
• Easy operation and programming via 17 ” LCD monitor . Incorporating windows based software makes for the efficient adding of new profiles and management of existing profiles to maintain optimum corner weld results .
• Heater plate Teflon renewal system is in roll form . Saves time and cost .
• Welding can be done by entering manual measurement without using the barcode reader .
INCLUDES :
• Full machine perimeter fencing with light beam safety gate .
• Barcode reader
• Ethernet connection
• Dedicated profile support blocks for a maximum of 5 various profiles .
• Full programming and set up .
• On-line support with remote access .
