diagrams at this stage. Notice that the Transitive relationship has
not yet been addressed.
3. Using the answer to exercise 3, remove all transitive
dependencies, and draw the new dependency diagrams. For each
new or revised table, specify its normal form.
Figure 3 – Solution 3
Discussion: The transitive relationship has been removed by
creating the Publishers table, in which PubName is fully dependent
upon PubCode. Pubcode also persists as a dependent attribute and
Foreign Key in Books. All tables are now in 3NF, and have been
given meaningful na mes reflecting the entities they represent.
LINEITEMS represents the collection of line items for all invoices.
Invoices represents the collection of Invoices for all customer
orders. Books makes up the list of all books available for sale
(whether they have ever been ordered or not). Each book has a
publisher, and the publisher code and Name reside in the Publishers
table.
4. Draw the ERD for exercise 3, using Crow‘s Foot notation.
End of Sample Exercise.
Student Exercise
The student exercise for this lab is similar to the sample exercise
presented above.
Consider the following spreadsheet containing information about
customers, their shipping and billing addresses, and the countries
