must be able to associate multiple medications sold on a single
prescription number.
Patient Patient Number, First Name, Last Name, Address, City, State,
Zip, Phone Number A patient can be associated with multiple
prescriptions, but any one prescription is to one and only one patient.
A prescription can occur without a patient registering in the system
(e.g., an unconscious patent arrives by ambulance in the emergency
room and receives life-saving emergency treatment).
Using an appropriate drawing/data modelling tool, develop an ERD
that meets the following guidelines.
• Draw the entities with their attributes.
• Indicate the relationships between the entities using Crow‘s Foot
notation. You will need to determine the cardinality and optionality for
each direction of the relationships. Some of the Foreign Key
relationships are identified in the graph above but not all. Be sure you
identify and account for all Foreign Key relationships.
• Add a name (in both directions) to the relationships. Remember, if
you can verbalize the relationship in both directions, then you
probably have a valid relationship.
Deliverables
The deliverable for this lab will be your completed ERD as a single MS
Word document using copy/paste or imported as an image from your
drawing/modelling application, cropped and sized appropriately (it
should fit on a single page), and named lab2_solutions_yourname.
LAB STEPS
STEP 1: Drawing Entities and Attributes
