Altrex PRO + Altrex PRO +
Step-overs
• 45 ° or 60 ° stepladder
• Tread width of 60, 80 or 100 cm
• Sturdy non-skid extrusion or crude profiled punched treads( both 21.5 cm deep)
• Standing height of 0,60 m up to max. 2,20 m
• Provided as standard with mounting profiles for floor assembly
EN 14122 EN 14122
STEP-OVERS
Step-over 45 ° 3 4 5 6 7 8 9 10 11 Max. height under platform( cm)( H) 48 68 88 108 128 148 168 188 208 Spread( cm)( S) 173.5 213.5 253.5 293.5 333.5 373.5 413.5 453.5 493.5 Platform length( cm)( B) 64.5 64.5 64.5 64.5 64.5 64.5 64.5 64.5 64.5 Step 224523 224524 224525 224526 224527 224528 224529 224530 224530 Guardrail 224543 224544 224545 224546 224547 224548 224549 224550 224551
Step-over 60 °
Straight stairs
• 45 ° or 60 ° stepladder
• Tread width 60, 80 or 100 cm
• Sturdy non-skid extrusion or crude profiled punched treads( both 21.5 cm deep)
• Standing height from 0,80 m up to a max. 4 m
Max. height under platform( cm)( H) 61.5 86 110.5 135 159.5 184 208.5-- Spread( cm)( S) 139 167.5 195.5 224 252.5 280.5 309-- Platform length( cm)( B) 64.5 64.5 64.5 64.5 64.5 64.5 64.5-- Step 226023 226024 226025 226026 226027 226028 226029-- Guardrail 226043 226044 226045 226046 226047 226048 226049--
B
45 °
S
B
60 °
S
H
H
95
