BATTISCOPA FILOMURO
SKIRTING FLUSH WITH THE WALL
STRIP è il sistema battiscopa filomuro in alluminio a triplo uso
(brevettato), composto dalla base e dal battiscopa. La base ha la
funzione di rifinire la parete e supportare il battiscopa, può essere
installata indistintamente su pareti in muratura o cartongesso ed è
dotata di apposite scanalature di irrigidimento atte ad ospitare le
varie giunzioni lineari ed angolari, per un assemblaggio rapido e
preciso. Il battiscopa, grazie alla sua particolare sagoma, può
essere applicato a chiusura totale della base o lasciando una fuga
di 3 mm fra se e l’intonaco. Inoltre, il battiscopa STRIP, può essere
retro illuminato con una comune striscia a led per delineare i
percorsi. La base è già predisposta per questa applicazione,
mentre al battiscopa basta togliere l’aletta di chiusura con una
semplice operazione manuale a “strappo” per far passare la luce.
Installazione a
chiusura totale
Total closure
installation
Installazione con
fuga da 3 mm
3 mm leak
installation
Installazione con
illuminazione a led
Led lightining
installation
3
STRIP is the skirting flush with the wall system in aluminium with three use
(patented), composed by the base and by the baseboard. The base has the
function of to finish the wall support and the skirting board, it can be installed
without distinction on the walls or plasterboard and is provided with suitable
stiffening grooves adapted to accommodate the various junctions and linear
angular, for a fast and precise assembly. The skirting board, thanks to its
particular shape, can be applied total closure of the base or a shadow gap of 3
mm between itself and the plaster. In addition, the baseboard STRIP, can be
backlit with a common strip led light to outline paths. The base is already
prepared for this application, while the skirting board, remove only the flap
closure a simple manual operation to "pull" to let the light pass.
Plasterboard wall
Masonry wall
In masonry walls, it is advisable to secure the base with foam or
structural adhesive. In plasterboard walls, fix the base directly to the
metal structure with conventional screws. Install the baseboard after
installing the floor and painting of the walls, using the supplied
double-sided tape or silicone adhesives business.
The profile "Base" can also accommodate wooden skirting commercial.
Parete in muratura
Nelle pareti in muratura, è consigliabile fissare la base con
schiume o adesivi strutturali. Nelle pareti in cartongesso,
fissare la base direttamente alla struttura metallica con normali viti. Installare il battiscopa dopo la posa del pavimento e
l’imbiancatura delle pareti, tramite il biadesivo in dotazione o
con adesivi siliconici commerciali.
Il profilo “Base” può anche accogliere battiscopa in legno di
tipo commerciale.
Parete in cartongesso
POSA IN OPERA / INSTALLATION
COMPONENTI / COMPONENTS
BS 01
Base per battiscopa
(barre da 2 mt.)
Base for skirting
(2 mt. bars)
Battiscopa con aletta
asportabile per luce a Led.
(Barre da 2 mt)
Disponibile in tutti i colori Ral.
BS 51
Built-in frame for
pull opening doors
Flexible Junction for
variable corners
Telaio incassato per porte
con apertura a tirare
20
Il battiscopa dal design puro e minimale che delinea
l’ambiente senza limitarlo.
9
BS 11
9.5
Base raccordata per porte
con aper tura a spingere
58 60
Skirting board STRIP with LED backlighting.
BS 53
Coppia tappi terminali
Terminal pair caps
Giunzione fissa 90°
per gradini
Fix junction 90°
for steps
Base connected for doors
with push opening
80
Battiscopa STRIP con retro illuminazione a Led.
Giunzione flessibile
per angoli variabili
BS 52
13
The skirting board with pure and minimal design to outline the ambient
without limit it.
24
IBS 100
Skirting with removable flap for
Led light. (2 mt. bars)
Available in all Ral colors.
15
STRIP
BS 02
57.5
55
25
