MATERIAL DE FIXAÇÃO
FIJACIONES
FIXING MATERIAL
MATÉRIEL POUR LA FIXATION
Abraçadeiras agrupáveis
para cabos e tubos
c/ bucha M6 rápida
Abrazaderas
para cables y tubos
con taco M6 rapido
Saddles for cables and/or
conduits with
M6 fast dowell
Attache pour câbles et/ou
conduits avec
cheville M6 rapide
Abraçadeiras de
serrilha agrupáveis
para cabos tipo clip
c/ bucha
Série 500M6 rápida
Abrazaderas
de cierre agrupables
para cables tipo clip
con taco M6 rapido
Serie 500
Pressure saddles
for cable with
M6 fast dowell
Embase a pression
a justaposer pour câble
avec cheville M6 rapide
-15ºC
+90ºC
M6
Material termoplástico
Material termoplastico
Thermoplastic material
Matériel thermoplastique
Aplicação pressão
Aplicación presión
Pressure aplication
Applicacion à pression
Bucha
Taco
Dowel
Cheville
Cores
Colores
Colours
Couleurs
90 º
Agrupável
Apilable
Stackable
Empilable
CAB.
Ref.
(mm)
2035/D
12-20
50
2037/D
Abrazaderas para cabley tubo
enlazables serie 200 c/
taco M6 rapido
50
2036/D
Abraçadeiras agrupáveis para
cabos e tubos série 200 c/
bucha M6 rápida
6-13
16-26
50
Saddles type 200
(for cable and/or conduit)
with M6 fast dowell
Attache type 200
(pour câble et/ou conduit)
avec cheville M6 rapide
-30ºC
+90ºC
M6
Material termoplástico
Material termoplastico
Thermoplastic material
Matériel thermoplastique
Aplicação pressão
Aplicación presión
Pressure aplication
Applicacion à pression
Bucha
Taco
Dowel
Cheville
90 º
Cores
Colores
Colours
Couleurs
E
Ref. BM6
Agrupável
Apilable
Stackable
Empilable
B
C
A
Dim. (mm)
Ref.
C
D
E
F
IEC
PG
IRO
211/D
21,5
15,3
10
25,6
11
16
16
11
-
100
28
19,6
10
29
14,2
16
20
13,5
19
100
208/D
F
B
204/D
D
A
32,2
24,3
10
34,1
17,4
16
25
-
23
100
