Diving Board Accessories & Anchors
35-185
DIVING STAND ANCHORS
PARAGON DIVING STAND ANCHORS —
Paragon Diving Stands include Anchor Bolt
Assembly when originally purchased. The
Flanged Stub Anchor or the Cage Anchor
can be substituted as the anchor for the
flanged pedestal for additional charge, both
available in carbon steel or stainless steel.
ANCHOR BOLT ASSEMBLY — Standard
diving tower anchor. Includes template for
accurate setting and alignment of flanged
tower pedestal.
35-185
PLATFORM MATTING
UNDERWATER WINDOWS
PARAGON UNDERWATER WINDOWS —
Rectangular and round styles. Installs in any
poured concrete or gunite pool with plain, tile,
or plaster finish. Stainless steel frame with 3
ply (3/8" thick each) tempered glass laminate or
single thickness 11/4" Plexiglas. Round windows
are constructed from powder coated cast
bronze frames with 2 plies of 3/8" tempered glass
or single thickness of 3/4" Plexiglas. Windows
are pressure tested and factory sealed. Custom
windows or windows designed for custom
depths also available — inquire.
Window
Glass
Opening Glazing
24" x 24"
24" x 36"
24" x 48"
24" x 60"
36" x 36"
36" x 48"
36" x 60"
18" dia.
35-220
35-230
35-240
35-250
35-260
35-270
35-280
35-290
Max Plexiglas Max
Depth Glazing Depth
14' 6"
8' 6"
7' 0"
6' 3"
6' 6"
4' 3"
3' 6"
14' 6"
35-225
35-235
35-245
35-255
35-265
35-275
•
35-295
16' 6"
9' 3"
6' 6"
6' 0"
4' 9"
3' 0"
•
8' 9"
DIVETEX MATTING — Provides superior foot
traction and consistent response. Vulcanized
rubber with molded embossed surface,
channels water away. 1/2" thick, in 2 different
widths, and priced per square foot. Use
adhesive to anchor matting in place.
35-300 3' wide
35-310 5' wide
35-316 Adhesive, 1.9 gallon
CAGE ANCHOR — For installation on a beam
or slab of any thickness greater than 6". Must
be used when diving tower is to be supported
on a framed slab.
35-188 Carbon steel
35-189 Stainless steel
SAFETY PADDING SYSTEMS
SOFTSIDE™ SAFETY PADS — Designed
specifically for aquatic applications. Used
under slide flumes, spray features, and diving
boards. Durable PVC covered-safety foam
padding system meets all CPSC guidelines
and complies with fall-zone regulations. Foam
is totally watertight and is formulated with
biocides to resist mold and algae growth. Can
be installed underwater or above waterline,
either indoors or outdoors. Very easy to
maintain. For existing facilities, padding is
“tapered on grade” and for new facilities,
padding is “flush with grade”. Includes
mounting hardware. Padding material is
colorfast and UV-stabilized to resist fading.
Colors: white, light blue, Caribbean blue, or
French blue. Available in 1/2" - 4" thick, with
custom texture options. 2 Year Warranty.
35-320 SoftSide Safety Pad, 3' x 4'
35-321 SoftSide Safety Pad, 3' x 5'
35-322 SoftSide Safety Pad, 4' x 6'
35-323 SoftSide Safety Pad, 4' x 8'
35-324 SoftSide Safety Pad, custom
Your Lincoln Representative can help you
design the Soft-Water Landing System to
best meet your needs. Inquire.
82
35-186
35-189
FLANGED STUB ANCHOR ASSEMBLY —
For use when tower is supported by a
foundation pad, on grade or in a framed beam,
if it's at least 18" deep.
35-186 Carbon steel
35-187 Stainless steel
REAR ANCHOR ASSEMBLY —
Anchor for rear legs of Paragon
diving stands. Two-piece heavy
cast bronze with chrome plate
upper flange.
37-025
34-010
34-055
DURAFIRM STAND ANCHORS — Cast bronze
deck anchor for 1M and 3M stand, set of 8.
Includes 1/2" x 5" bolts for positioning in cement
and 5/8" x 1" bolts for layout positioning. Short
stand anchors, set of six, same as 1M and 3M
anchors, except does not include 5" bolt. For
existing decks (1M and 3M stands) - Concrete
threaded insert kit (set of 8) with epoxy. Available
with or without epoxy dispenser. Stand anchor
bolts purchased separately.
34-010 Deck anchors, set of 8 (1M & 3M)
34-055 Deck anchors, set of 6 (Short Stand)
34-065 Inserts w/disp., set of 8 (1M & 3M)
34-070 Inserts w/o disp., set of 8 (1M & 3M)
35-520 Anchor bolt, 5/8" x 13/4"
35-525 Anchor bolt, 5/8" x 2"
35-530 Anchor bolt, 5/8" x 21/2"
35-535 Anchor bolt, 5/8" x 3"
